VLT ® HVAC Drive Instruction Manual
8 Specifications
8.1 General Specifications
Normal overload 110% for 1 minute
Line power supply 200–240 V AC
Adjustable frequency drive
Typical Shaft Output [kW]
IP 20 / Chassis
IP 21 / NEMA 1
IP 55 / NEMA 12
IP 66 / NEMA 12
Typical Shaft Output [HP] at 208 V
Output current
Continuous
(3 x 200–240 V) [A]
Intermittent
(3 x 200–240 V) [A]
Continuous
kVA (208 V AC) [kVA]
Max. cable size:
(line power, motor, brake)
[mm
Max. input current
Continuous
(3 x 200–240 V) [A]
Intermittent
(3 x 200–240 V) [A]
Max. pre-fuses
Environment
Estimated power loss
at rated max. load [W]
Weight enclosure IP20 [kg]
Weight enclosure IP21 [kg]
Weight enclosure IP55 [kg]
Weight enclosure IP66 [kg]
Efficiency
2 /AWG] 2)
1) [A]
4)
3)
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
P1K1 P1K5 P2K2
1.1 1.5 2.2
A2 A2 A2
A2 A2 A2
A5 A5 A5
A5 A5 A5
1.5 2.0 2.9
6.6 7.5 10.6
7.3 8.3 11.7
2.38 2.70 3.82
4/10
5.9 6.8 9.5
6.5 7.5 10.5
20 20 20
63 82 116
4.9 4.9 4.9
5.5 5.5 5.5
13.5 13.5 13.5
13.5 13.5 13.5
0.96 0.96 0.96
8 Specifications
P3K0 P3K7
3 3.7
A3 A3
A3 A3
A5 A5
A5 A5
4.0 4.9
12.5 16.7
13.8 18.4
4.50 6.00
11.3 15.0
8
12.4 16.5
32 32
155 185
6.6 6.6
7.5 7.5
13.5 13.5
13.5 13.5
0.96 0.96
