6 How to program the adjustable frequency
drive
2-10 Brake Function
Option:
[0] * Off
[1] Resistor brake
[2] AC brake
2-17 Over-voltage Control
Option:
[0] Disabled
[2] * Enabled
6
NOTE!
The ramp time is automatically adjusted to avoid tripping of the adjustable frequency drive.
3-02 Minimum Reference
Range:
0.000 Ref- [-999999.999 - par. 3-03 Referen-
erenceFeed- ceFeedbackUnit]
backUnit*
3-03 Maximum Reference
Range:
50.000 Ref- [par. 3-02 - 999999.999 Referen-
erenceFeed- ceFeedbackUnit]
backUnit*
6-26
Function:
No brake resistor installed.
Brake resistor incorporated in the system, for dissipation of surplus braking energy as heat. Con-
necting a brake resistor allows a higher DC link voltage during braking (generating operation). The
resistor brake function is only active in adjustable frequency drives with an integral dynamic brake.
Function:
Overvoltage control (OVC) reduces the risk of the adjustable frequency drive tripping due to over-
voltage on the DC link caused by generative power from the load.
No OVC required.
Activates OVC.
Function:
Enter the Minimum Reference. The minimum reference is the lowest value obtainable by summing
all references. The minimum reference value and unit matches the configuration choice made in
par.1-00 Configuration Mode and par. 20-12
NOTE!
This parameter is used in open-loop only.
Function:
Enter the maximum acceptable value for the remote reference. The Maximum Reference value and
unit matches the configuration choice made in par.1-00
ence/Feedback Unit
, respectively.
NOTE!
If operating with par. 1-00, Configuration Mode set for Closed-loop [3], par.
20-14, Maximum Reference/Feedb. must be used.
