VLT ® HVAC Drive Instruction Manual
Danfoss PN
20220
20221
Table 4.5: Additional Fuses for Non-UL Applications, E enclosures, 380–480 V
Size/Type Bussmann PN*
P355 170M4017
170M5013
P400 170M4017
170M5013
P500 170M6013
P560 170M6013
Table 4.6: E enclosures, 525–600 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use.
Danfoss PN
20220
20221
Table 4.7: Additional Fuses for Non-UL Applications E enclosures, 525–600 V
Suitable for use on a circuit capable of delivering not more than 100,000 rms symmetrical amperes, 500/600/690 Volts maximum when protected by the
above fuses.
If UL/cUL is not to be complied with, we recommend using the following fuses, which will ensure compliance with EN50178:
In case of malfunction, not following the recommendation may result in unnecessary damage to the adjustable frequency drive.
P110 - P200
P250 - P450
Table 4.8: Additional High Power Non-UL compliance
UL Compliance
Adjustable
frequency Bussmann
drive
200–240 V
kW Type RK1
K25-K37 KTN-R05
K55-1K1 KTN-R10
1K5 KTN-R15
2K2 KTN-R20
3K0 KTN-R25
3K7 KTN-R30
5K5 KTN-R50
7K5 KTN-R50
11K KTN-R60
15K KTN-R80
18K5 KTN-R125
22K KTN-R125
30K FWX-150
37K FWX-200
45K FWX-250
Table 4.9: UL fuses 200–240 V
Bussmann
170M4017
170M6013
Danfoss PN
20220
20220
20221
20221
Bussmann
170M4017
170M6013
380 –500 V
380 –500 V
Bussmann Bussmann
Type J Type T
JKS-05 JJN-05
JKS-10 JJN-10
JKS-15 JJN-15
JKS-20 JJN-20
JKS-25 JJN-25
JKS-30 JJN-30
JKS-50 JJN-50
JKS-60 JJN-60
JKS-60 JJN-60
JKS-80 JJN-80
JKS-150 JJN-125
JKS-150 JJN-125
- -
- -
- -
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
Ferraz
6.9URD31D08A0700
6.9URD33D08A0900
Rating
700 A, 700 V
700 A, 700 V
900 A, 700 V
900 A, 700 V
Ferraz
6.9URD31D08A0700
6.9URD33D08A0900
SIBA Littel fuse
Type RK1 Type RK1
5017906-005 KLN-R005
5017906-010 KLN-R10
5017906-015 KLN-R15
5012406-020 KLN-R20
5012406-025 KLN-R25
5012406-030 KLN-R30
5012406-050 KLN-R50
5012406-050 KLN-R60
5014006-063 KLN-R60
5014006-080 KLN-R80
2028220-125 KLN-R125
2028220-125 KLN-R125
2028220-150 L25S-150
2028220-200 L25S-200
2028220-250 L25S-250
4 Electrical installation
Siba
20 610 32.700
20 630 32.900
Losses (W)
85
85
120
120
Siba
20 610 32.700
20 630 32.900
type gG
type gR
Ferraz- Ferraz-
Shawmut Shawmut
Type CC Type RK1
ATM-R05 A2K-05R
ATM-R10 A2K-10R
ATM-R15 A2K-15R
ATM-R20 A2K-20R
ATM-R25 A2K-25R
ATM-R30 A2K-30R
- A2K-50R
- A2K-50R
A2K-60R A2K-60R
A2K-80R A2K-80R
A2K-125R A2K-125R
A2K-125R A2K-125R
A25X-150 A25X-150
A25X-200 A25X-200
A25X-250 A25X-250
