20-04 Feedback 2 Conversion
Option:
[0] * Linear
[1] Square root
[2] Pressure to temperature
20-06 Feedback 3 Source
Option:
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
20-07 Feedback 3 Conversion
Option:
[0] * Linear
[1] Square root
[2] Pressure to temperature
20-20 Feedback Function
Option:
[0] Sum
Function:
See par.20-01 Feedback 1 Conversion
Function:
Feedback 1 Source
See par.20-00
Function:
See par.20-01 Feedback 1 Conversion
Function:
This parameter determines how the three possible feedbacks will be used to control the output
frequency of the adjustable frequency drive.
Sum [0] sets up the PID controller to use the sum of Feedback 1, Feedback 2 and Feedback 3 as
the feedback.
NOTE!
Any unused feedbacks must be set to
Source
, par.20-03
The sum of Setpoint 1 and any other references that are enabled (see par. group 3-1*) will be used
as the PID controller's setpoint reference.
