VLT ® HVAC Drive Instruction Manual
2.1.3 Type Code String
Description
Product group & FC Series
Power rating
Number of phases
AC line voltage
Enclosure
RFI filter
Brake
Display
Coating PCB
Line power option
Adaptation
Adaptation
Software release
Software language
A options
B options
C0 options MCO
C1 options
C option software
D options
Table 2.1: Type code description.
The various options and accessories are described further in the
Pos Possible choice
1-6 FC 102
8-10 1.1–560 kW (P1K1 - P560)
11 Three phases (T)
T 2: 200–240 V AC
11-12 T 4: 380–480 V AC
T 6: 525–600 V AC
E20: IP20
E21: IP 21/NEMA Type 1
E55: IP 55/NEMA Type 12
E2M: IP21/NEMA Type 1 w/ line power shield
13-15
E5M: IP 55/NEMA Type 12 w/ line power shield
E66: IP66
P21: IP21/NEMA Type 1 w/ backplate
P55: IP55/NEMA Type 12 w/ backplate
H1: RFI filter class A1/B
H2: RFI filter class A2
16-17
H3: RFI filter class A1/B (reduced cable length)
H4: RFI filter class A2/A1
X: No brake chopper included
B: Brake chopper included
18
T: Safe Stop
U: Safe + brake
G: Graphical Local Control Panel (GLCP)
19 N: Numeric Local Control Panel (NLCP)
X: No Local Control Panel
X. No coated PCB
20
C: Coated PCB
X: No line power disconnect switch
21 1: With line power disconnect switch (IP55 only).
See Chapter 8 for max. cable sizes.
22 Reserved
23 Reserved
24-27 Current software
28
AX: No options
A0: MCA 101 Profibus DP V1
29-30 A4: MCA 104 DeviceNet
AG: MCA 108 Lonworks
AJ: MCA 109 BACnet gateway
BX: No option
BK: MCB 101 General purpose I/O option
31-32
BP: MCB 105 Relay option
BO: MCB 109 Analog I/O option
33-34 CX: No options
35 X: No options
36-37 XX: Standard software
DX: No option
38-39
D0: DC backup
VLT HVAC Drive Design Guide, MG.11.BX.YY
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
