VLT ® HVAC Drive Instruction Manual
1-20 Motor Power [kW]
Range:
4.00 kW* [0.09 - 3000.00 kW]
1-21 Motor Power [HP]
Range:
4.00 hp* [0.09 - 3000.00 hp]
1-22 Motor Voltage
Range:
400. V* [10. - 1000. V]
1-23 Motor Frequency
Range:
50. Hz* [20 - 1000 Hz]
NOTE!
This parameter cannot be adjusted while the motor is running.
1-24 Motor Current
Range:
7.20 A* [0.10 - 10000.00 A]
NOTE!
This parameter cannot be adjusted while the motor is running.
1-25 Motor Nominal Speed
Range:
1420. RPM* [100 - 60000 RPM]
Function:
Enter the nominal motor power (in kW) according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running. Depending on the choices made in
Regional Settings
par. 0-03 , either par.1-20
made invisible.
Function:
Enter the nominal motor power in HP according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Depending on the choices made in par. 0-03
Motor Power [HP]
or par.1-21 is made invisible.
Function:
Enter the nominal motor voltage according to the motor nameplate data. The default value corre-
sponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Function:
Select the motor frequency value from the motor nameplate data.For 87 Hz operation with 230/400
V motors, set the nameplate data for 230 V/50 Hz. Adapt par.4-13
Maximum Reference
and par.3-03
Function:
Enter the nominal motor current value from the motor nameplate data. This data is used for cal-
culating motor torque, motor thermal protection, etc.
Function:
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
6 How to program the adjustable frequency
Motor Power [kW]
or par.1-21
Regional Settings
, either par.1-20
Motor Speed High Limit [RPM]
to the 87 Hz application.
drive
Motor Power [HP]
is
Motor Power [kW]
