VLT ® HVAC Drive Instruction Manual
Size/Type Bussmann PN*
P315 170M5013
P355 170M6013
P400 170M6013
P450 170M6013
Table 4.13: E enclosures, 380–480 V
Size/Type
P355
P400
P450
P500
P560
Table 4.14: E enclosures, 525–600 V
*170M fuses from Bussmann shown, use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use.
4.1.3 Grounding and IT line power
The ground connection cable cross-section must be at least 0.016 in
according to EN 50178 or IEC 61800-5-1
tions on cable cross-sections.
The line power is connected to the main disconnect switch if this is included.
NOTE!
Make sure that the AC line voltage corresponds to the AC line voltage of the adjustable frequency drive nameplate.
Figure 4.1: Terminals for line power and grounding.
IT Line Power
Do not connect 400 V adjustable frequency drives with RFI filters to line power supplies with a voltage between phase and ground of
more than 440 V.
For IT line power and delta ground (grounded leg), AC line voltage may exceed 440 V between phase and ground.
Danfoss PN
20221
20221
20221
20221
Bussmann JFHR2*
170M5013/170M4017
170M5013/170M4017
170M6013
170M6013
170M6013
unless national regulations specify differently. Always comply with national and local regula-
MG.11.A9.22 - VLT ® is a registered Danfoss trademark
Rating
900 A, 700 V
900 A, 700 V
900 A, 700 V
900A, 700 V
SIBA Type RK1 FERRAZ-SHAWMUT Type RK1
2061032.700
2061032.700
2063032.900
2063032.900
2063032.900
2 [10 mm 2 ]or 2 rated line power wires terminated separately
4 Electrical installation
Losses (W)
120
120
120
120
900 A, 700 V
900 A, 700 V
900 A, 700 V
900A, 700 V
4
4-5
