7 Troubleshooting
No. Description
1 10 Volts low
2 Live zero error
3 No motor
4 Line phase loss
5 DC link voltage high
6 DC link voltage low
7 DC overvoltage
8 DC undervoltage
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor overtemperature
12 Torque limit
13 Overcurrent
14 Ground fault
15 Incomp. HW
16 Short Circuit
17 Control word timeout
22 Hoist mech. brake
23 Internal fans
24 External fans
25 Brake resistor short-circuited
7
26 Brake resistor power limit
27 Brake chopper short-circuited
28 Brake check
29 Power board overtemp.
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Soft-charge fault
34 Serial communication bus fault
36 Line failure
37 Phase imbalance
38 Internal fault
39 Heatsink sensor
40 Overload T27
41 Overload T29
42 Overload X30/6-7
46 Pwr. card supply
47 24 V supply low
48 1.8 V supply low
49 Speed limit
50 AMA calibration failed
51 AMA check U
nom
52 AMA low I
nom
53 AMA motor too big
54 AMA motor too small
55 AMA parameter out of range
56 AMA interrupted by user
57 AMA timeout
58 AMA internal fault
59 Current limit
60 External interlock
61 Tracking error
62 Output Frequency at Maximum Limit
64 Voltage Limit
65 Control Board Overtemperature
66 Heatsink Temperature Low
67 Option Configuration Has Changed
68 Safe Stop Activated
69 Pwr. card temp.
70 Illegal FC configuration
Table 7.1: Alarm/Warning code list 1/2
7-2
and I
nom
MG.11.A9.22 - VLT
Warning Alarm/Trip Alarm/Trip Lock
X
(X) (X)
(X)
(X) (X)
X
X
X X
X X
X X
(X) (X)
(X) (X)
X X
X X
X X
X
X
(X) (X)
X
X
(X) (X)
X X
(X) (X)
X X
(X) (X)
(X) (X)
(X) (X)
X
X X
X X
X
X
X
X X
X
X
X
X
X
X
X
X
X
X X
X
X X
X
X
X X
X
X
X
X
