MEMOBUS Register
Number
0C8BH
0C8CH
0C8DH
0C8EH
0C8FH
The example below shows reading and setting parameters.
• Example 1: When setting 256 (100H) to the parameter of the MEMOBUS register number
1200H
•Write the register number (1200 H) that you want to set to register number 0C00H
(register number setting 1)
•Write the value (100H) to be written to register number 1200H in register number
0C80H
Details for settings and readings are as follows:
1. Set the command code (2C00H) to remote register RW
2. Set the write data (1200H) to remote register RW
3. Switch on the RYF signal (request to execute the command code).
4. Set the command code (2C80H) to remote register RW
5. Set the write data (100H) to remote register RW
6. Switch on the RYF signal (request to execute the command code).
256(100H) is set to the parameter of register number 1200(H).
• Example 2: When reading the parameter of the MEMOBUS register number 1500H with
the register number setting 9
•Write the register number (1500H) that you want to set to register number 0C08H
(register number setting 9)
•Read the value of the register number 1200H from the register number 0C88H
Details for settings and readings are as follows:
1. Set the command code (2C08H) to remote register RW
2. Set the write data (1500H) to remote register RW
3. Switch on the RYF signal (request to execute the command code).
4. Set the command code (1C88H) to remote register RW
5. Switch on the RYF signal (request to execute the command code).
The parameter value of register number 1500H is stored in remote register RW
YASKAWA ELECTRIC TOBP C730600 83C YASKAWA AC Drive Option SI-C3 Installation Manual
Parameter contents of register number in setting 12
Parameter contents of register number in setting 13
Parameter contents of register number in setting 14
Parameter contents of register number in setting 15
Parameter contents of register number in setting 16
7 Basic Functions
Descriptions
.
W2
.
W3
.
W2
.
W3
.
W2
.
W3
.
W2
.
R3
