How to Install
4 4
1069
1068.91 mm
[42,08]
Illustration 4.11 Space in front of IP21/IP54 enclosure type, frame
size E9.
Wire access
Ensure that proper cable access is present including
necessary bending allowance.
NOTE
All cable lugs/ shoes must mount within the width of the
terminal bus bar.

4.3.3 Terminal Locations - Frame size D

Consider the following position of the terminals when
designing for cables access.
18
VLT Active Filter AAF 00x
597
597.00 mm
[23,50]
MG.90.V2.02 - VLT® is a registered Danfoss trademark
3x277,1
R/L1 91 S/L T/L3 93
[10.9]
0
[.0]
Illustration 4.12 Terminal Location of Frame D9
3X 276,87
[10.9]
0
[.0]
Illustration 4.13 Terminal Location of Frame D13
Be aware that the power cables are heavy and hard to
bend. Consider the optimum position of the unit for
ensuring easy installation of the cables.

4.3.4 Terminal Locations - Frame size E

Take the following position of the terminals into consid-
eration when designing the cable access.
332.5
[13.1]
.0
[.0]
Illustration 4.14 Terminal Location of Frame E7
