7010 / 7017SF Technical Reference Manual
7017 / 7017SF Technical Reference
Manual
Table of Contents
Section 1
Service Call Procedures
Section 2
Status Indicator Repair Analysis Procedures
Section 3
Image Quality
Section 4
Repair / Adjustment
Section 5
Parts List
Section 6
General Procedures / Information
Section 7
Wiring Data
Section 8
Store and Forward Option
http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/7017stoc.htm [28/09/1999 11:33:51]
www.printcopy.info

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Telecopier 7017 and is the answer not in the manual?

Questions and answers

Related Manuals for Xerox Telecopier 7017

Summary of Contents for Xerox Telecopier 7017

  • Page 1 Section 2 Status Indicator Repair Analysis Procedures Section 3 Image Quality Section 4 Repair / Adjustment Section 5 Parts List Section 6 General Procedures / Information Section 7 Wiring Data Section 8 Store and Forward Option www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/7017stoc.htm [28/09/1999 11:33:51]...

  • Page 2: Table Of Contents

    1.2.1 Prepare for System Checks 1.2.2 Off-Line System Check 1.2.3 On-Line System Check 1.3 Additional System Checks 1.3.1 G2 On-Line Check 1.3.2 Store and Forward Check 1.3.3 Automatic Document Feeder Check 1.4 Final Actions 1.4.1 Call Completion www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section1.htm [28/09/1999 11:33:53]...

  • Page 3: Introduction Call Flow Procedures

    Error Code List and follow the actions indicated. In the event Service Call Procedures do not isolate the problem call for assistance. Image Quality RAPs Repair Spare Parts List 7017-104 Figure 1 Call Flow 6/88 Introduction, Call Flow, Procedures Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 4: Prepare For System Checks

    Press Enter. d. If listen to dial is on, go to next step. If listen to dial is off, press Select to change to on. e. Press Enter. 8/88 Prepare for System Checks, Off-Line System Check Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 5 NOTE: If extended operation of printer is 23. Original is unwrinkled. desired, perform RAP 2.3.7 Paper Feed Test. Replace A2, A6, speaker. Check platen belt (RAP 2.3.11); replace A2, scan motor. 12/88 Off-Line System Check Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 6: On-Line System Check

    Store and forward option 1.3.2 terminal is acceptable. (Image quality acceptance is determined by the remote Automatic Document Feeder 1.3.3 operator’s perception of quality.) (multiple originals) RAP 2.3.13. 12/88 Off-Line System Check, On-Line System Check Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 7 Store and forward option 1.3.2 terminal is acceptable. (Image quality acceptance is determined by the remote Automatic Document Feeder 1.3.3 operator’s perception of quality.) (multiple originals) RAP 2.3.13. 12/88 Off-Line System Check, On-Line System Check Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 8: 1.3 Additional System Checks

    Replace A8, A2. 8. Return to procedure which directed you COMMUNICATIONS MODE >G2 to this check or go to Final Actions. PRESS [START] OR [SCROLL] 8. Press Enter. 12/88 G2 On-Line, Store & Forward Checks Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 9: Automatic Document Feeder Check

    Press Start. (multiple originals) into input tray. 3. Enter Service Mode. 10. Refer to Service Options Report printed 3. Enter Original Feed Test. NOTE: Use Xerox CLEAN-UPS to perform the during Prepare For System Check (if following cleaning functions...
  • Page 10 RAP 2.3.8 Sensor Test 2-12 RAP 2.3.9 Scanner Test 2-14 RAP 2.3.10 Automatic Document Feeder Test 2-14 RAP 2.3.11 Belt Checkout 2-16 RAP 2.3.12 Both LEDs Remain On 2-16 RAP 2.3.13 Received Image Quality is Unacceptable 2-16 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section2.htm [28/09/1999 11:34:11]...

  • Page 11: Status Indicator Repair Analysis Procedures

    A2 PWB. Then run System Check again to verify that replacing A5 PWB has resolved the problem. If the problem is still not resolved, call for assistance. If the problem is resolved, go to Final Actions. 8/88 Introduction Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 12: 2.2 Error Code List

    Replace A2, A5, A10 E243 Replace A2, A5, A10 E244 Replace A2, A5, A10 E245 Replace A2, A5, A10 E246 Replace A2, A5, A10 E248 Replace A2, A5, A10 12/88 CXXX, FPXX, EXXX Error Codes Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 13: 2.2.4 Fcxx Error Codes

    FC26 Replace A2 FC27 Replace A2 FC28 Replace A2 FC29 Replace A2 FC30 Replace A2 FC31 Replace A2 FC32 Replace A2 FC33 Replace A2 FC34 Replace A2 FC37 Replace A8 12/88 EXXX, FCXX Error Codes Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 14 FC26 Replace A2 FC27 Replace A2 FC28 Replace A2 FC29 Replace A2 FC30 Replace A2 FC31 Replace A2 FC32 Replace A2 FC33 Replace A2 FC34 Replace A2 FC37 Replace A8 12/88 EXXX, FCXX Error Codes Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 15 RECORDING JAM-CLEAR PAPER PATH OP36 OP36 Recording paper remained by the RECEIVED DOCUMENT IN MEMORY Check printer jam sensor (RAP 2.3.8), jam sensor. (Special case) RECORDING JAM-CLEAR PAPER PATH OP36 replace A2 8/88 OPXX Error Codes Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 16: Opxx Error Codes

    SCANNER COVER IS OPEN-PLEASE CLOSE COVER Check scan interlock switch (RAP 2.3.8); OP80 replace A2 OP81 Printer cover open. PRINTER COVER IS OPEN-PLEASE CLOSE COVER Check printer interlock switch (RAP 2.3.8); OP81 replace A2 8/88 OPXX Error Codes Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 17: 2.3 Status Indicator Raps

    Figure 1. wiring. 7017-107 3. Replace A2. Problem resolved. Go to Step 5. 4. Go to Final Actions. 8/88 RAP 2.3.1 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 18 (or improper wiring). AC Power Connector Figure 5. 7017-111 Remove jumper from J3 and reinstall power supply. Perform Load Isolation RAP 2.3.2. Problem resolved. Call for assistance. 18. Go to Final Actions. 8/88 RAP 2.3.1 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 19: Rap 2.3.2 Load Isolation

    Both LEDs TP41 TP-LG of power supply come on. Go to Step 10. 9. Replace thermal head. Figure 1. 7017-112 Note: Ignore any display fault codes which may appear during this procedure. 12/88 RAP 2.3.2 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 20: Rap 2.3.3 Diagnostic Pattern Is Unacceptable

    5. Connect the black meter lead to TP-LG (Figure 1). 6. Connect power cord to terminal. 7. Connect the red meter lead to one of the test points listed in Figure 1 (TP12, TP13, TP14, TP15). 8/88 RAPS 2.3.3, 2.3.4 2-10 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 21: Rap 2.3.5 The Terminal Does Not Answer

    Replace pulley or E-ring. 6. Inspect upper scanner. Upper scanner closes and latches. Replace latch spring, latches. 7. Inspect upper printer. Upper printer closes and latches. Replace latch spring, latches or printer frame. 12/88 RAPS 2.3.5, 2.3.6 Telecopier 7017 / 7017SF 2-11 www.printcopy.info...

  • Page 22: Rap 2.3.7 Paper Feed Test

    Printer Jam Sensor Cutter switch Scan position sensor Low paper sensor Wide paper sensor (FX, RX only) Ring Indicator Hook Signal Fax Net Ring Indicator (FX only) Replace applicable sensor. 12/88 RAPS 2.3.7, 2.3.8 www.printcopy.info 2-12 Telecopier 7017 / 7017SF...
  • Page 23 (Gears) Cutter crank Printer belt Print motor Cutter clutch, Cutter Planet gears, Cutter crank solenoid and pulley pulley (Note 2) Figure 1. Print Drive System (Viewed from Left Side) 7017-105 6/88 Print Drive System Telecopier 7017 / 7017SF 2-13 www.printcopy.info...

  • Page 24: Rap 2.3.9 Scanner Test

    (multiple originals) into input tray. 8. Enter Original Feed Test. a. Press Menu. b. On the key pad, press 7 then 2. The display indicates: ORIGINAL FEED PRESS [START] OR [SCROLL] 12/88 RAPS 2.3.9, 2.3.10 2-14 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 25 ADF Drive shaft Scan input drive belt Scan input drive roller Scan output drive belt Scan motor Scan output drive roller Figure 1. Scan Drive System (Viewed from Left Side) 7017-106 6/88 Scan Drive System Telecopier 7017 / 7017SF 2-15 www.printcopy.info...

  • Page 26: Rap 2.3.11 Belt Checkout

    Center (TSC). Request to receive (not in Error Correct mode) from their terminal. Image quality is acceptable. (Refer to Section 3 for image quality.) Inform Customer of telephone line problem. 6. Go to Final Actions. 8/88 RAPS 2.3.11, 2.3.12 2-16 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 27 IQ 1.1b Diagnostic Test Pattern (Lower Half) IQ 1.2 Test Pattern 82P151 IQ 1.3 Test Pattern 82P151 (Wide Original) IQ 1.4 Noise on Line, non-ECM IQ 1.5 Noise on Line, ECM or non-ECM IQ 1.6 Modem Noise www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section3.htm [28/09/1999 11:34:48]...

  • Page 28: Introduction

    Test Pattern 82P151 (copied on the terminal). Samples of telephone line noise and modem noise are also included. Image Quality Samples comparison to identify any image quality defects which may have been produced during System Check. 12/88 Introduction Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 29: Iq 1.1A Diagnostic Test Pattern (Upper Half)

    IQ 1.1a Diagnostic Test Pattern (Upper Half) 7017-100 www.printcopy.info 6/88 IQ 1.1a Telecopier 7017 / 7017SF...

  • Page 30: Iq 1.1B Diagnostic Test Pattern (Lower Half)

    IQ 1.1b Diagnostic Test Pattern (Lower Half) 6/88 www.printcopy.info IQ 1.1b Telecopier 7017 / 7017SF...

  • Page 31: Iq 1.2 Test Pattern 82P151

    IQ 1.2 Test Pattern 82P151 6/88 www.printcopy.info IQ 1.2 Telecopier 7017 / 7017SF...

  • Page 32: Iq 1.3 Test Pattern 82P151, Wide Original

    IQ 1.3 Test Pattern 82P151, Wide Original 6/88 www.printcopy.info IQ 1.3 Telecopier 7017 / 7017SF...

  • Page 33: Iq 1.4 Noise On Line, Non-Ecm

    IQ 1.4 Noise on Line, non-ECM 12/88 www.printcopy.info IQ 1.4 Telecopier 7017 / 7017SF...

  • Page 34: Iq 1.5 Noise On Line, Ecm Or Non-Ecm

    IQ 1.5 Noise on Line, ECM or non-ECM 12/88 IQ 1.5 www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 35: Iq 1.6 Modem Noise

    IQ 1.6 Modem Noise 12/88 IQ 1.6 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 36 REP 3.8 Scan Pulley / Gear 4-20 REP 3.9 Scan Input Drive Roller 4-20 REP 3.10 Scan Output Drive Roller 4-21 REP 3.11 Scan Output Drive Pulley 4-21 REP 3.12 Scan Motor 4-22 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section4.htm (1 of 3) [28/09/1999 11:36:44]...
  • Page 37 4-43 REP 5.3 Fan 4-43 REP 5.4 A8 Store & Forward PWB 4-44 REP 5.5 A2 Main PWB 4-44 REP 5.6 Power Supply Assembly 4-45 REP 5.7 A3 Telephone Line Filter PWB 4-46 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section4.htm (2 of 3) [28/09/1999 11:36:44]...
  • Page 38 4. Repair / Adjustment REP 5.8 A5 Modem PWB 4-46 REP 5.9 A10 Coupler PWB 4-47 REP 5.10 CNC PWB Assembly 4-47 Electronics ADJ 5.1 Cutter Registration 4-48 ADJ 5.2 Scan Registration 4-52 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section4.htm (3 of 3) [28/09/1999 11:36:44]...

  • Page 39: Introduction

    (listed under the repair title) for It also contains a functional check of the locating most components within a procedure. component part or assembly. 6/88 Repair / Adjustment Introduction Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 40: Rep 1.1 Document Catch Tray Assembly

    Slide RH cover towards the right to clear the upper scan cover and the base plate, then pull it up and towards the rear to clear the A8 store & forward PWB, if installed. 12/88 REP 1.1, 1.2 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 41: Rep 1.3 Coupler Cover

    Replacement 5. Press output tray assembly down to ensure it is fully seated. Reinstall in reverse order. 6. Reinstall document catch tray assembly (REP 1.1). 6/88 REP 1.3, 1.4, 1.5 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 42: Rep 1.6 Rear Cover

    2. Ensure W4 wire harness is not pinched by Replacement the upper scan cover. Reinstall in reverse order. 3. Reinstall in reverse order. 6/88 REP 1.6, 1.7, 1.8 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 43: Rep 1.9 Input Tray / Printer Cover Assembly

    5. If replacing input tray / printer cover 3. Reinstall recording paper. assembly, remove input tray extension (REP 1.10). 4. Close printer. Replacement 5. Reinstall document catch tray assembly (REP 1.1). Reinstall in reverse order. 6/88 REP 1.9, 1.10, 1.11 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 44: Rep 2.1 Retard Assembly

    Position paper weights in cutouts in nudger arm, then position nudger arm on top of the nudger roller. e. Rotate retard assembly align cutout on nudger timing gear with cutout on nudger clutch. 12/88 REP 2.1, 2.2 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 45: Rep 2.3 Pad Assembly

    Remove E-ring securing pad shaft. Remove shaft, paper weights, and nudger arm. g. Remove E-ring securing assembly. h. Remove pad assembly, LH and RH retard springs, and spring spacer. Remove LH and RH hooks if installed. 12/88 REP 2.3 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 46: Rep 2.13 Nudger Solenoid Assembly

    Secure nudger solenoid assembly with the screw. b. Rotate nudger pawl towards the rear to remove nudger solenoid plunger. 3. Reinstall remaining components reverse order. 12/88 REP 2.12, 2.13 4-14 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 47: Rep 2.14 Nudger Pawl And Nudger Pawl Spring

    11.Remove nudger pawl and nudger pawl spring. (Figure 1) a. Rotate nudger pawl away from nudger clutch. b. Remove nudger pawl spring from LH frame. c. Remove nudger pawl and nudger pawl spring. 12/88 REP 2.14, 3.1 Telecopier 7017 / 7017SF 4-15 www.printcopy.info...

  • Page 48: Rep 3.2 Scan Interlock Switch

    9. Remove CNC PWB assembly (REP 5.10). 10. Remove scan interlock switch. a. Remove scan interlock switch harness from cable clamp. b. Remove screw securing scan interlock switch. c. Remove scan interlock switch. 12/88 REP 3.1, 3.2 4-16 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 49 9. Remove CNC PWB assembly (REP 5.10). 10. Remove scan interlock switch. a. Remove scan interlock switch harness from cable clamp. b. Remove screw securing scan interlock switch. c. Remove scan interlock switch. 12/88 REP 3.1, 3.2 4-16 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 50: Rep 3.3 Scan Input Idler Roller

    Reinstall in reverse order. g. Remove RH platen bearing. Remove scan input idler roller. h. Remove platen roller. Replacement Reinstall in reverse order. 12/88 REP 3.3, 3.4 Telecopier 7017 / 7017SF 4-17 www.printcopy.info...

  • Page 51: Rep 3.5 Scan Output Idler Roller

    Remove LH E-ring from scan pivot shaft. Remove LH scan pivot bearing. g. Remove scan pivot springs while removing the scan pivot shaft. h. Remove upper scan assembly. 12/88 REP 3.5, 3.6 4-18 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 52: Rep 3.7 Video Assembly

    RH frame. c. Lift video assembly to access W11 wire harness. d. Disconnect J201 from video assembly. Replacement e. Remove video assembly. Reinstall in reverse order. 12/88 REP 3.7 Telecopier 7017 / 7017SF 4-19 www.printcopy.info...

  • Page 53: Rep 3.8 Scan Pulley / Gear

    Remove scan pulley/gear. from LH frame. b. Remove E-ring and brass bearing from RH frame. c. Remove scan input drive roller. d. Remove bearings. Replacement Reinstall in reverse order. 12/88 REP 3.8, 3.9 4-20 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 54: Rep 3.10 Scan Output Drive Roller

    Remove scan output drive pulley from scan output drive roller. e. Remove scan output drive roller and plastic bearing from LH frame. Remove bearings from scan output drive roller. Replacement Reinstall in reverse order. 12/88 REP 3.10, 3.11 Telecopier 7017 / 7017SF 4-21 www.printcopy.info...

  • Page 55: Rep 3.12 Scan Motor

    1. If scan motor was replaced, delete J115 b. Remove the two screws from the scan on the connector. motor. 2. Reinstall in reverse order. c. Remove scan motor through the RH frame. 12/88 REP 3.12 4-22 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 56: Rep 4.1 Low Paper Sensor And Rx: Wide Paper Sensor

    4. Remove sensor. (Figure 1) a. Disconnect jack from sensor: J408 low paper sensor J409 RX: wide paper sensor b. Remove screw securing sensor. c. Remove sensor. 12/88 REP 4.1 Telecopier 7017 / 7017SF 4-23 www.printcopy.info...

  • Page 57: Rep 4.2 Printer Jam Sensor

    (Figure 1 of REP 4.1) 4. Reposition jam sensor bracket in locating slot on upper printer frame and on locating point, then secure with screw. 5. Reinstall remaining components reverse order. 12/88 REP 4.2, 4.3 4-24 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 58: Rep 4.4 Recording Paper Supply Indicator

    Remove indicator spring from the RH reverse order. frame. b. Press a small screwdriver through the access holes in the base frame (Figure 1) to release the recording paper supply indicator. 12/88 REP 4.4 Telecopier 7017 / 7017SF 4-25 www.printcopy.info...

  • Page 59: Rep 4.5 Lower Paper Guide Assembly

    2. Position locating pin in LH frame. Replacement 3. Reinstall remaining components 1. Position three locating tabs in cutouts in reverse order. base frame. 2. Reinstall remaining components reverse order. 12/88 REP 4.5, 4.6 4-26 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 60: Rep 4.7 Upper Printer Assembly

    Remove LH and RH printer pivot bearings. Remove printer pivot shaft from RH frame. g. Remove printer pivot shaft from LH frame. h. Remove upper printer assembly. 12/88 REP 4.7 Telecopier 7017 / 7017SF 4-27 www.printcopy.info...

  • Page 61: Rep 4.8 Printer Output Idler Rollers

    Remove E-ring securing LH printer cam bearing. c. Remove LH printer cam bearing and LH printer pivot spring. d. Slide printer pivot shaft to the right to remove printer output idler rollers. Continued 12/88 REP 4.7, 4.8 4-28 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 62 Remove E-ring securing LH printer cam bearing. c. Remove LH printer cam bearing and LH printer pivot spring. d. Slide printer pivot shaft to the right to remove printer output idler rollers. Continued 12/88 REP 4.7, 4.8 4-28 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 63: Rep 4.9 Cutter

    Do not handle the pivoting blade on the cutter. It has a sharp edge. 1. Reposition cutter. 2. Bias cutter to rear and secure with screws. 3. Reinstall remaining components reverse order. 12/88 REP 4.8, 4.9 Telecopier 7017 / 7017SF 4-29 www.printcopy.info...
  • Page 64 Do not handle the pivoting blade on the cutter. It has a sharp edge. 1. Reposition cutter. 2. Bias cutter to rear and secure with screws. 3. Reinstall remaining components reverse order. 12/88 REP 4.8, 4.9 Telecopier 7017 / 7017SF 4-29 www.printcopy.info...

  • Page 65: Rep 4.10 Printer Output Drive Roller

    Be sure to 6. Remove upper printer assembly (REP 4.7). reinstall it, if it was previously installed. 7. Remove printer output drive roller. (Figure 1) Reinstall in reverse order. 12/88 REP 4.10 4-30 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 66: Rep 4.11 Pressure Roller Assembly

    Remove RH and LH pressure roller bearings. d. Loosen setscrew in pressure roller drive gear. e. Slide pressure roller assembly fully left to position pressure roller drive gear against LH frame. Remove pressure roller assembly. 12/88 REP 4.11 Telecopier 7017 / 7017SF 4-31 www.printcopy.info...

  • Page 67: Rep 4.12 Thermal Head Assembly

    2. Reinstall in reverse order. b. Rotate thermal head assembly forward and slide off studs on RH and LH frames. c. Disconnect J301 and J302 at thermal head assembly. 12/88 REP 4.12 4-32 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 68: Rep 4.13 Cutter Crank Arm

    8. Remove cutter crank arm (REP 4.13). b. RX: Remove spring. 9. Remove cutter cam. c. Remove the cutter crank arm. a. Depress cutter solenoid plunger. b. Remove cutter cam. Replacement Reinstall in reverse order. 12/88 REP 4.13, 4.14 Telecopier 7017 / 7017SF 4-33 www.printcopy.info...

  • Page 69: Rep 4.15 Printer Motor

    14. Remove printer motor. (Figure 1) a. Remove the three screws securing the printer motor. b. Loosen printer belt at printer motor. c. Remove printer motor harness from twist tie. d. Remove printer motor. 12/88 REP 4.15 4-34 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 70: Rep 4.16 Cutter Belt

    2. Reinstall screw securing cutter switch. CAUTION Position wires away from cutter belt. 3. Secure cutter switch harness in cable clamp. 4. Replace cable tie. (Figure 1) 5. Reinstall remaining components reverse order. 12/88 REP 4.16, 4.17 Telecopier 7017 / 7017SF 4-35 www.printcopy.info...

  • Page 71: Rep 4.18 Cutter Home Lever And/Or Cutter Home Spring

    6. Remove the cutter belt. 7. Remove the cutter switch (REP 4.17). 8. Remove the cutter home lever and cutter home spring. a. Release the cutter home spring from the LH frame tab. (Figure 1) 12/88 REP 4.18 4-36 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 72: Rep 4.19 Planetary Assembly

    Ensure 70P87 is not on external surfaces of the planetary assembly. 2. Ensure shoulders of the three planet gear #2 are positioned towards the brass gear (planet gear #1). 3. Reinstall in reverse order. 12/88 REP 4.19 Telecopier 7017 / 7017SF 4-37 www.printcopy.info...

  • Page 73: Rep 4.20 Cutter Crank Pulley

    16. Remove cutter crank pulley. (Figure 1) 2. Reinstall remaining components reverse order. a. Remove E-ring securing the cutter crank pulley. b. Remove the cutter crank pulley. c. Remove both cutter crank bearings. 12/88 REP 4.20, 4.21 4-38 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 74: Rep 4.22 Cutter Solenoid Assembly

    LH frame. d. Remove cutter solenoid assembly. 3. Secure cutter solenoid assembly to the LH frame with the two screws. 4. Reinstall in reverse order. 12/88 REP 4.21, 4.22 Telecopier 7017 / 7017SF 4-39 www.printcopy.info...
  • Page 75 LH frame. d. Remove cutter solenoid assembly. 3. Secure cutter solenoid assembly to the LH frame with the two screws. 4. Reinstall in reverse order. 12/88 REP 4.21, 4.22 Telecopier 7017 / 7017SF 4-39 www.printcopy.info...

  • Page 76: Rep 4.23 Cutter Solenoid Lever

    Remove screw securing LH frame to e. Remove cutter solenoid lever from power supply housing. the stud on the LH frame. c. Remove screw (located beneath cutter solenoid lever stud) securing LH frame to base frame. 12/88 REP 4.23 4-40 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 77: Rep 4.24 Printer Belt

    14. Remove pressure roller assembly (REP printer belt. 4.11). c. Remove printer belt. 15. Remove thermal head assembly (REP 4.12). Replacement Reinstall in reverse order. 12/88 REP 4.24 Telecopier 7017 / 7017SF 4-41 www.printcopy.info...
  • Page 78 Remove remaining screw securing control panel assembly to upper scan cover. e. Raise control panel assembly above upper scan cover. (Figure 2) Thread control panel assembly harness through the cutout in upper scan cover. 12/88 REP 5.1 4-42 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 79: Rep 5.2 Speaker Assembly

    Remove the two screws securing fan Replacement to power supply housing. Reinstall in reverse order. d. Remove fan from cutout in power supply housing. Replacement Reinstall in reverse order. 12/88 REP 5.2, 5.3 Telecopier 7017 / 7017SF 4-43 www.printcopy.info...

  • Page 80: Rep 5.4 A8 Store & Forward Pwb

    3. Reinstall in reverse order. c. Remove A2 main PWB. 7. If replacing A2 main PWB, perform the following: a. Remove A5 modem PWB (REP 5.8). b. Remove A10 coupler PWB (REP 5.9). 12/88 REP 5.4, 5.5 4-44 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 81: Rep 5.6 Power Supply Assembly

    3. If the PWB was replaced, check the following and adjust as needed: • Cutter Registration (ADJ 5.1) Figure 2. Location of E PROM U49 • Scan Registration (ADJ 5.2). 12/88 REP 5.5, 5.6 Telecopier 7017 / 7017SF 4-45 www.printcopy.info...

  • Page 82: Rep 5.7 A3 Telephone Line Filter Pwb

    7. Remove A5 modem PWB. (Figure 1) Replacement Replacement a. Remove A5 modem PWB from the Reinstall in reverse order. two modem standoffs. Reinstall in reverse order. b. Remove A5 modem PWB from J4. 12/88 REP 5.7, 5.8 4-46 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 83: Rep 5.9 A10 Coupler Pwb

    EME bracket and EME shield to base plate. e. Remove EME bracket. Remove screw securing CNC bracket to power supply housing. g. Remove CNC PWB assembly. h. Disconnect J120. Continued 12/88 REP 5.9, 5.10 Telecopier 7017 / 7017SF 4-47 www.printcopy.info...
  • Page 84 4. Position CNC bracket to align locating (Figure 2), the cutter registration is hole and point, then secure with screw. b. Clean exposed area correct. pressure roller using Xerox CLEAN- 5. Reinstall and/or replace remaining e. If six or more lines are printed on the UPS.
  • Page 85 4. Position CNC bracket to align locating (Figure 2), the cutter registration is hole and point, then secure with screw. b. Clean exposed area correct. pressure roller using Xerox CLEAN- 5. Reinstall and/or replace remaining e. If six or more lines are printed on the UPS.

  • Page 86: Adj 5.1 Cutter Registration

    (positive) resulting in too much white space on trail edge. following test pattern illustrates cutter registration adjustment early (negative) resulting in too many lines on lead edge and too few lines on trail edge. Continued 12/88 ADJ 5.1 Telecopier 7017 / 7017SF 4-49 www.printcopy.info...
  • Page 87 0000: -4.0 0110: -1.0 1100: +2.0 (mm) 0001: -3.5 0111: -0.5 1101: +2.5 0010: -3.0 1000: ±0 1110: +3.0 0011: -2.5 1001: +0.5 1111: +3.5 0100: -2.0 1010: +1.0 0101:-1.5 1011: +1.5 12/88 ADJ 5.1 4-50 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 88 Press Stop. The terminal will reboot and retain the changes. 6. Verify that new setting achieves the correct position by performing the Check again. Reposition as needed. 7. Check the scan registration. (ADJ 6.2) 12/88 ADJ 5.1 Telecopier 7017 / 7017SF 4-51 www.printcopy.info...

  • Page 89: Adj 5.2 Scan Registration

    If registration arrows on the lead checking the Scan registration. edge are equal to the registration b. Press the Start button. 1. Clean the following using Xerox CLEAN- arrows on the trail edge (Figure 2), UPS: c. Highlight Systems Data Setup No. 10 the scan registration is correct.
  • Page 90 The following test pattern illustrates the scan registration adjustment too early (negative) resulting in the trail edge registration arrow being cut off. Continued 12/88 ADJ 5.2 Telecopier 7017 / 7017SF 4-53 www.printcopy.info...
  • Page 91 0000: -4.0 0110: -1.0 1100: +2.0 (mm) 0001: -3.5 0111: -0.5 1101: +2.5 0010: -3.0 1000: ±0 1110: +3.0 0011: -2.5 1001: +0.5 1111: +3.5 0100: -2.0 1010: +1.0 0101:-1.5 1011: +1.5 12/88 ADJ 5.2 4-54 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 92 Enter to effect the change. Press Stop. The terminal will reboot and retain the changes. 6. Verify that new setting achieves the correct position by performing the Check again. Reposition as needed. 12/88 ADJ 5.2 Telecopier 7017 / 7017SF 4-55 www.printcopy.info...
  • Page 93 PL 5.2 Control Panel and Speaker 5-16 PL 5.3 PWBs and Handset 5-17 PL 5.4 CNC PWB and Line Filter 5-18 PL 5.5 CNC Wire Harnesses 5-19 Miscellaneous PL 6.1 Electrical Connectors 5-20 Common Hardware 5-21 Parts Number Index 5-22 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section5.htm [28/09/1999 11:39:16]...

  • Page 94: Parts List Introduction

    The asterisk * appears in the parts listing and install the Tag/MOD. The Change Tag/MOD applies to Xerox USO and RX distribution. The Exploded illustrations of spared subsystem Index will either list a kit number (600K...) or asterisk indicates that the part can be ordered...

  • Page 95: Pl 1.1Trays

    Operator Guide (USO) 002K84571 Operator Guide Jacket Output Tray 073K98042 Document Catch Tray Assembly Catch Tray 009E85170 Catch Tray Spring Output Tray Base 073K98032 Output Tray Assembly (USO) 073K98671 Output Tray Assembly (RX) 12/88 www.printcopy.info PL 1.1 Telecopier 7017 / 7017SF...

  • Page 96: Pl 1.2Covers

    091P66413 Customer Assistance Label (USO) 091E77050 Telephone Number Label (USO) 068E86002 Handset Cradle (USO) 002E88731 Coupler Cover (USO) 002E88741 Coupler Cover (RX) 002K75243 Input Tray/Printer Cover Assembly 499K95949 RH Cover Kit (RX) 12/88 PL 1.2 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 97: Pl 1.3Frames

    LH Frame 032E96041 Paper Side Plate #1 091P80361 Tag/MOD Matrix 032E96051 Paper Side Plate #2 RH Frame Serial Number Plate Base Frame Power Supply Housing Base Plate 499K95609 Feet Foot CNC Guide 12/88 PL 1.3 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 98: Pl 2.1Upper Adf

    Nudger Arm Spring Pad Shaft RH Cam / Stopper RH Retard Spring Spring Spacer LH Retard Spring 007E96870 Nudger Timing Gear 006K95781 Retard Assembly 499K95736 Spring Hook Kit RH Hook LH Hook 12/88 www.printcopy.info PL 2.1 Telecopier 7017 / 7017SF...

  • Page 99: Pl 2.2Lower Adf

    Nudger Solenoid Assembly ** 006K95821 ADF Drive Shaft Assembly N O T E : I f n u d g e r solenoid assembly replaced, discard spring and nylon washer on solenoid plunger. 12/88 PL 2.2 www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 100: Pl 3.1Upper Scan Electronics

    Latch Spring 003K96090 Scanner Latch 110K95780 Scan Interlock Switch Upper Scan Frame 499K95607 Scan Pivot Spring Kit LH Scan Pivot Spring RH Scan Pivot Spring 003E98240 Retard Stop Pad Retard Stop Bracket 12/88 www.printcopy.info PL 3.1 Telecopier 7017 / 7017SF...

  • Page 101: Pl 3.2Upper Scan Drives

    Platen Spring 013E96640 RH Platen Bearing 022K85060 Scan Input Idler Roller 022K85051 Platen Roller 022K85070 Scan Output Idler Roller 020E95990 Platen Pulley Platen Spacer 023E96130 Platen Belt (45 MXL) Upper Scan Assembly 12/88 www.printcopy.info PL 3.2 Telecopier 7017 / 7017SF...

  • Page 102: Pl 3.3Lower Scan

    Plastic Bearing #8 (P/O PL 2.2 Item 16) 127K97730 Scan Motor 020E95980 Scan Output Drive Pulley 023E96110 Scan Output Drive Belt (106 MXL) 020E95970 Scan Pulley/Gear 023E96120 Scan Input Drive Belt (118 MXL) 12/88 PL 3.3 5-10 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 103: Pl 4.1Upper Printer

    Printer Pivot Shaft 009E98920 Latch Spring 011K95570 Printer Release Lever 003K96110 Printer Latch 499K95611 Printer Output Idler Roller Kit Printer Output Idler Roller 110K95790 Printer Interlock Switch Upper Printer Frame Upper Printer Assembly 12/88 www.printcopy.info PL 4.1 Telecopier 7017 / 7017SF 5-11...

  • Page 104: Pl 4.2Cutter And Pressure Roller

    Cutter Crank Arm (P/O Tag/MOD 4) (RX) (P/O Item 14) Pressure Roller Assembly Cutter Crank Arm Spring (P/O Tag/MOD 4) (RX) (P/O Item 14) 499K95853 Cutter Crank Arm Kit (Tag/MOD 4) (RX) 12/88 www.printcopy.info PL 4.2 5-12 Telecopier 7017 / 7017SF...

  • Page 105: Pl 4.3Thermal Head

    J301 (P/O PL 5.5 Item 16) J302 (P/O PL 5.5 Item 1) 499K95599 Thermal Head Spring Kit Thermal Head Spring 038E96730 Printer Motor Cover 038K96222 Lower Paper Guide Assembly (USO) 038K96401 Lower Paper Guide Assembly (RX) www.printcopy.info 12/88 PL 4.3 Telecopier 7017 / 7017SF 5-13...

  • Page 106: Pl 4.4Printer Drives

    Cutter Home Stop 011K95660 Cutter Crank Pulley 499K95597 Cutter Home Lever Kit Cutter Home Spring Cutter Home Lever 020E95950 Thumbwheel Pulley 023E96090 Cutter Belt (100 MXL) 110K95800 Cutter Switch 121K97052 Cutter Solenoid Assembly 12/88 www.printcopy.info PL 4.4 5-14 Telecopier 7017 / 7017SF...

  • Page 107: Pl 5.1Power Supply

    Power Cord (RX: Switzerland) Fuse Cover 108E96020 Power Supply Fuse (6.3 AMP) (USO) 108E96030 Power Supply Fuse (3.15 AMP) (RX) Power Supply 105K96211 Power Supply Assembly (USO) 105K96222 Power Supply Assembly (RX) www.printcopy.info 12/88 PL 5.1 Telecopier 7017 / 7017SF 5-15...

  • Page 108: Pl 5.2Control Panel And Speaker

    7017SF Overlay (USO) 091E77000 7017 Overlay (RX) 091E77010 7017SF Overlay (RX) One Touch Overlay (USO) 091E89810 One Touch Overlay (RX) Xerox Telecopier 7017 Job Card / Overlay Kit (Customer Supply Item) 12/88 www.printcopy.info PL 5.2 5-16 Telecopier 7017 / 7017SF...

  • Page 109: Pl 5.3Pwbs And Handset

    (Tag/MOD 2) (USO, RX) 140K75480 A2 Main PWB (Tag/MOD 6) (USO, RX) 140K89941 A2 Main PWB (Tag/MOD 50) (RX) 140K75501 A2 Main PWB (Tag/MOD 6) (OLV) Coupler Standoff Modem Standoff Main Standoff www.printcopy.info 12/88 PL 5.3 Telecopier 7017 / 7017SF 5-17...

  • Page 110: Pl 5.4Cnc Pwb And Line Filter

    Filter PWB and Line Filter Bracket) (RX) A0 CNC PWB CNC Bracket EME Shield Fastener EME Bracket 499K95615 CNC PWB Assembly 068E76140 PWB Retainer (USO) PWB Retainer (RX) (P/O PL 1.2 Item 16) 12/88 PL 5.4 5-18 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 111: Pl 5.5Cnc Wire Harnesses

    W11 Wire Harness (with J123 and J201) 152K94791 W9 Wire Harness (with J120 and J301) J119 (P/O PL 5.1 Item 1) W8 Wire Harness (RX) 152K94770 W7 Wire Harness (with J116 and J408) 12/88 www.printcopy.info PL 5.5 Telecopier 7017 / 7017SF 5-19...

  • Page 112: Pl 6.1Electrical Connectors

    Cable Clamp Kit (USO) Cable Clamp 600S00697 Cable Tie Kit Cable Tie Twist Tie (use PL 6.1 Item 2 for replacement) Cable Clamp (use PL 6.1 Item 1 for replacement) 7017-215 12/88 PL 6.1 5-20 Telecopier 7017 / 7017SF www.printcopy.info...

  • Page 113: Common Hardware

    E-Ring #6 Nylon Washer ** 251W31151 Brass Washer (W/O Tag/MOD 3) 354W27254 KL-Ring 252W31550 Black Washer (W/O Tag/MOD 3) Nylon Washer ** ** NOTE: Mandatory if originally installed. Otherwise, none installed. 12/88 Common Hardware Telecopier 7017 / 7017SF 5-21 www.printcopy.info...

  • Page 114: Parts Number Index

    499K95949 009E98891 032E96041 117E06270 152P92552 600S00697 009E98920 032E96051 117P80447 152S92956 009E98920 032E96102 117P91798 152S92957 009E98941 037K95153 121E96121 152S92959 009E99800 038E96730 121K97052 499K95597 011K95490 038E96930 125E95151 499K95599 011K95570 038E96950 125E95160 499K95600 12/88 Part Number Index 5-22 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 115 Install the Telephne Number Label Install the Store and Forward Option Install the Power Cord Entering the Date and Time 6-10 Entering Local ID Number 6-11 Checking Time Digits 6-11 Checking Copy Operation 6-11 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section6.htm (1 of 3) [28/09/1999 11:40:57]...
  • Page 116 6-45 Test Group B, Touch Tone Test 6-45 Test Group C, System Data Setup 6-45 Test Group C, RAM Clear 6-46 Test Group C, Counters Reset 6-46 Test Group C, Service Diagnostics 6-47 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section6.htm (2 of 3) [28/09/1999 11:40:57]...
  • Page 117 6. General Procedures / Information Special Facility Menu, G3 Send Speed 6-48 Special Facility Menu, G3 Rec Speed 6-48 Special Facility Menu, Comm Mode 6-48 Special Facility Menu, Protocol Monitor6-49 Glossary of Mnemonics 6-50 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section6.htm (3 of 3) [28/09/1999 11:40:57]...

  • Page 118: Introduction

    “System Test and information,“ this section of the manual contains all the test procedures contained terminals software and general procedures. A glossary of mnemonics has been added to the end of this section 6/88 Introduction www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 119: Specifications And Space Requirements

    @ 50 Hz ± 1 Hz or 60 Hz ± 1 Hz 200 to 240 VAC (nominal 220 VAC) @ 50 Hz ± 1 Hz or 60 Hz ± 1 Hz 6/88 Specifications and Space Requirements www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 120 5” Top View Front View 24” 60” 5” ” Minimum 18” Maximum 36” 24” 40” 7017-300 Figure 1. Specification and Space Requirements 6/88 Specifications and Space Requirements www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 121: Tools And Supplies

    600T1617 DVM Leads kit 600T40201 Screwdriver 4” X 1/4” 600T40206 Phillips pocket screwdriver 600T40207 Jewelers Screw Driver 600T40212 Xcelite handle 600T40502 Combination wrench, 7.0 mm 600T40702 Socket, 7.0mm (1/4 Inch drive) 12/88 Tools and Supplies www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 122: Telephone Requirements (Uso)

    (USOC RJ11C) supplied by the telephone company. FCC Registration Number AQX63C-19885-DP-R Ringer Equivalence = 0.5 B Application up to 9600 BPS Facsimile Telephone may be rotary, Touch-Tone ® , or pulse Dial. 6/88 Telephone Requirements www.printcopy.info Telecopier 7017 /7017SF...

  • Page 123: Installation

    B4 (15 cards each set) • Operator Guide RX (Only) • Control Panel overlay in English Record all necessary details required by your • 2 - Product identification Labels (7017 organization. Label and 7017 SF label). 6/88 Installation www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 124: Install The Output Tray

    Move the paper toward the rear until it cover. is visible beyond the pressure roller. Output Tray f. Close the printer cover. Paper Drive Roller Inner Bracket Rear Rear Lower Frame Cover Side View of Rear (Tray Installed) 6/88 Installation www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 125: Install The Telephone Handset

    Locate the notch in the cradle. c. Place the handset on the cradle. PLEASE WAIT g. Place the label in the notch. Telecopier 7017 and various LED‘s on the control panel will light. 12/88 Installation www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 126: Entering The Date And Time

    Clear key and enter the correct digits. a. Enter two digits for the month. (For example, enter 02 for February.) The display will indicate: ENTER DATE THEN TIME 02-01-88 02:36PM 8/88 Installation www.printcopy.info 6-10 Telecopier 7017 / 7017SF...

  • Page 127: Entering Local Id Number

    If the comparison does not agree, refer to level 1 . After the copy is complete, the display will again indicate: LOAD ORIGINALS FACE DOWN IN INPUT TRAY 3:14 PM 2- 27 88 12/88 Installation www.printcopy.info Telecopier 7017 / 7017SF 6-11...
  • Page 128 Press the Start key again to continue the diagnostics. The terminal will print a test pattern towards the end of diagnostics. When diagnostics is complete, the display will momentarily indicate: DIAGNOSTICS COMPLETE 6/88 Installation www.printcopy.info 6-12 Telecopier 7017 / 7017SF...
  • Page 129 Position A10 SW 1 bit 3 to the ”OFF“ indicating Service (PSR) Mode is position. disabled. d. Reinstall the coupler cover. e. Reinstall power cord. f. Select Menu 53. Display indicates: NOT AVAILABLE 12/88 Installation www.printcopy.info Telecopier 7017 / 7017SF 6-13...
  • Page 130 ATT 2 ATT 1 SW 1 16 8 4 2 1 2 4 8 OFF ON A10 Coupler A3 Line Filter igure 1 RX A10 Coupler and A3 Line Filter PWB 7017-302 6/88 Installation www.printcopy.info 6-14 Telecopier 7017 / 7017SF...
  • Page 131 ATTR P701 P901 P901 A10 Coupler A3 Line Filter Figure 2 US A10 Coupler and A3 Line Filter PWB 7017-303 6/88 Installation www.printcopy.info Telecopier 7017 / 7017SF 6-15...
  • Page 132 Table 1 USO/XC A10 Coupler ATT Switch Setting Transmit Power Level. Bit Definition Mfg. SETTING Note -1dBm CAUTION DO NOT CHANGE -2dBm USO / XC Transmit power -4dBm level -8dBm 6/88 Installation www.printcopy.info 6-16 Telecopier 7017 / 7017SF...
  • Page 133 Provides 0.5 dbm incremental step in transmit level ( see Table 4 ) Table 2A RX Coupler Links J4 and J5 THRESHOLD LINK J 4 LINK J 5 6 volts r.m.s 11 volts r.m.s. 16 volts r.m.s. 21 volts r.m.s. 8/88 Installation www.printcopy.info Telecopier 7017 / 7017SF 6-17...
  • Page 134 Remove Power to make changes. CONF. 4 Remove Power to Disabled Enabled Power UP to effect make changes. CONF. 5 Remote changes. Disabled Power UP to effect Diagnostic CONF. 6 changes. CONF. 7 12/88 Installation www.printcopy.info 6-18 Telecopier 7017 / 7017SF...
  • Page 135 NOTE 3: For Facsimile data receive levels there are two threshold levels provided, selectable via System Data 18, bit 1. Bit 1 ON = -47 dBm for group 3 (default) Bit 1 OFF = -43 dBm for group 3 12/88 Installation www.printcopy.info Telecopier 7017 / 7017SF 6-19...
  • Page 136 STOP key. While under control of the central terminal, the remote terminal control panel keys will be inoperative except for the STOP key. 8/88 Remote Diagnostics www.printcopy.info 6-20 Telecopier 7017 / 7017SF...
  • Page 137 Parameters. To do so may violate CCITT BITS another copy of the Options Report to Standards cause improper Terminal verify your selections. operations. Refer to Examples 1 and 2. DATA 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-21...
  • Page 138 Fallback at 1st. or 2nd. FTT First received DIS without NSF Accept or Ignore DIS Forced MH for 4800BPS Auto or Forced MH G2 Threshold Level for Modem Control Lightest to Darkest 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-22...
  • Page 139 1, 2, 3 or 4 times Protocol monitor Manual, Print on Error or Print Always Receive Header Print Auto, Forced or Disable Receive Header Print Logo Company Logo, Xerox Logo or Disable Receive to memory Enable or Disable Redial Enable or Disable Remote diagnostics...
  • Page 140 Lightest to Darkest Video Threshold Level Light Lightest to Darkest Video Threshold Level Dark Lightest to Darkest Voice Request Enable or Disable Wait Printing in ECM receiving Wait or Not Wait 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-24...
  • Page 141 Send Partial Batch Cancel Clock indication 24 hours 12 hours Manual RCV Mode Previous Mode Auto RCV Mode after job end Audible monitor Disable Enable Error correct mode Disable Enable 8/88 System Data Setup www.printcopy.info 6-25 Telecopier 7017 / 7017SF...
  • Page 142 :Forced :Disable :Auto FX only Line error rate to :10% :15% :20% send RTN Continuous error line with standard :6 lines :12 lines :24 lines :48 lines to send RTN 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-26...
  • Page 143 20 seconds after Description sending DIS. Voice Request Note 1 Enable Disable NOT USED NOT USED For halftone MTF disable MTF enable For halftone Light Dark NOT USED NOT USED NOT USED 8/88 System Data Setup www.printcopy.info 6-27 Telecopier 7017 / 7017SF...
  • Page 144 Stamp Off Stamp On NOT USED Transmission mode :Auto :4800BPS :N/A (FX only) Protocol monitor :Manual :Print in :Print :N/A error 1 always Service Mode Disable Enable Debug Mode Disable Enable 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-28...
  • Page 145 System Data: 11 Bit Definition Default System Data Bit No. Description G2 Threshold Level Examples: for Modem control. Bit Numbers 76543210 Binary Hex Code Note 00000000 Darkest 01110100 Default USO/RX 11111111 Lightest 8/88 System Data Setup www.printcopy.info 6-29 Telecopier 7017 / 7017SF...
  • Page 146 System Data: 15 Bit Definition Default System Data Bit No. Description Minimum recording :50mm :80mm :140mm :200mm length. NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-30...
  • Page 147 NOTE 2: Set to 1’s for Tag 2 terminals NOT USED and to 0’s for pre-Tag 2 terminals. NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED 8/88 System Data Setup www.printcopy.info 6-31 Telecopier 7017 / 7017SF...
  • Page 148 NOT USED mixed with signal during the second training. NOT USED NOT USED NOT USED NOT USED After Send EOR Continue Disconnect TAP Hold (Note 1) 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-32...
  • Page 149 NOT USED RL EQL for Modem T2 EQL for Modem T mode T/2 mode NOT USED J3L EQL for Modem NOT USED Wait printing in ECM Wait Not Wait receiving 8/88 System Data Setup www.printcopy.info 6-33 Telecopier 7017 / 7017SF...
  • Page 150 Note 3 bit 3 on RX A10 Coupler. Auto answer delay NOTE 3: :0 Sec :5 Sec :10 Sec :15 Sec Only available in terminals with Tag/MOD 2 or above. 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-34...
  • Page 151 Default System Data Bit No. Description Interval Timer for 4 Examples: Successful Dialings. Bit Numbers 76543210 Binary Hex Code Note 00000000 No Interval 00000101 Default 5 minutes 11111111 255 minutes 8/88 System Data Setup www.printcopy.info 6-35 Telecopier 7017 / 7017SF...
  • Page 152 00001110 : NORWAY 00000100 : FINLAND 00001111 : FRANCE 00000101 : GERMANY 00000110 : ITALY 00000111 : NETHERLANDS 00001000 : NEW ZEALAND 00001001 : SPAIN 00001010 : SWEDEN 00001011 : SWITZERLAND 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-36...
  • Page 153 Bit 6=1, Bit 7=1 Detect: The autodialer will look for the first dial tone and will also look for dial tone when a pause is inserted. 12/88 System Data Setup www.printcopy.info 6-37 Telecopier 7017 / 7017SF...
  • Page 154 011 : (3) 111 : (7) NOT USED NOT USED NOT USED Time out for end of : 35 sec : 48 sec : 60 sec : 90 sec dial. 8/88 System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-38...
  • Page 155 Cutter arm change adds spring to correct cutting problem with RX (USO) 31E95701 (USO) 49K017432 (USO) 49K017431 B4 thermal head. (RX) 499K95853 (RX) 59T559474 (RX) 59T559473 (XC) 49K062220 (XC) 49K062219 (OLV) 57U200421 (OLV) 57U200420 Table 1 Change Tag/MOD Index 12/88 Change Tag/MOD Index www.printcopy.info Telecopier 7017 / 7017SF 6-39...
  • Page 156 140K89941 (RX) 50 02.00 X01.14 X01.13 140K87946 Production X01.07 140K89910 Third Production Lot X01.08 140K87882 / 73K97960 Production 01.02 01.02 Table 2 Telecopier 7017 / 7017SF Firmware Matrix 12/88 Change Tag/MOD Index, Firmware Matrix www.printcopy.info 6-40 Telecopier 7017 / 7017SF...
  • Page 157 140K89941 (RX) 50 02.00 X01.14 X01.13 140K87946 Production X01.07 140K89910 Third Production Lot X01.08 140K87882 / 73K97960 Production 01.02 01.02 Table 2 Telecopier 7017 / 7017SF Firmware Matrix 12/88 Change Tag/MOD Index, Firmware Matrix www.printcopy.info 6-40 Telecopier 7017 / 7017SF...
  • Page 158 Start button. • Never place PWBs, integrated circuit chips or components on a metal surface. 12/88 Service Mode / Report, Diagnostics, Precautions www.printcopy.info Telecopier 7017 / 7017SF 6-41...
  • Page 159 (PPS-MPS) or (PPR) (CRP) (TSI) (NSS) (PPS-EOP) or MCF* (PPS-EOM) or (RNR) (PPS-PRI-MPS) or PIP* (PPS-PRI-EOP) or PIN* (PPS-PRI-EOM) or (CRP)* (RR) (RNR) (ERR) MCF* PIP* PIN* (CRP)* None 8/88 Pattern Prints, Protocol Monitor Print www.printcopy.info 6-42 Telecopier 7017 / 7017SF...
  • Page 160 Press the Stop button to end the test. Stop button is pressed. This will terminate the are fed, pressing the Stop button will test. terminate the test. 12/88 Tests: Paper Feed, Original Feed, Printer Motor www.printcopy.info Telecopier 7017 / 7017SF 6-43...
  • Page 161 A4 Document Sensor (FX) Printer Jam Sensor Cutter Switch Scan Position Sensor Low Paper Sensor Wide Paper Sensor (FX, RX) Ring Indicator Hook Signal Fax Net Ring Indicator (FX) 12/88 Tests: Scanner Motor, Sensor www.printcopy.info 6-44 Telecopier 7017 / 7017SF...
  • Page 162 1336HZ V29.26 1477HZ V29.72 1633HZ V27.48 “0“ V27.24 “1“ G2 WHITE/BLACK CARRIER “2“ “3“ “4“ “5“ “6“ “7“ “8“ “9“ “*“ “#“ “A“ “B“ “C“ “D“ 12/88 Tests: Frequency, Touch Tone, System Data Setup www.printcopy.info Telecopier 7017 / 7017SF 6-45...
  • Page 163 The following display will appear. RAM CLEAR >PROGRAM PRESS (SELECT) TO CHANGE THEN ENTER 4. Press the Enter button. This will clear all system RAM leaving the customer programmed information memory. 8/88 Ram Clear, Counters Reset www.printcopy.info 6-46 Telecopier 7017 / 7017SF...
  • Page 164 Not Used M68000 8255 Device Not Used M68000 D.P. RAM Option D.P. RAM M68000 D RAM S/F Option ROM/RAM M68000 DMA S/F Option D.P. RAM M68000 IDP S/F Diagnostics M68000 CG 8/88 Service Diagnostics www.printcopy.info Telecopier 7017 / 7017SF 6-47...
  • Page 165 Available speeds: Available speeds: Available modes: 9600 bps 9600 bps AUTO 7200 bps 7200 bps G3-STD 4800 bps 4800 bps 2400 bps 2400 bps 8/88 G3 Send Speed, G3 Rec Speed, Comm. Mode www.printcopy.info 6-48 Telecopier 7017 / 7017SF...
  • Page 166 62 is selected. report will reflect preceding operation. Errors A Protocol Monitor will print out upon detection of an error. Always A Protocol Monitor will print out automatically after every operation. 8/88 Protocol Monitor www.printcopy.info Telecopier 7017 / 7017SF 6-49...
  • Page 167 Self check Indication ”Good” Transmitting Subscriber Loop 1 Made Identification Loop 2 Made TL EQL Transmit Link Amplitude Equalizer Self check Indication ”No Good” German Configuration 6 Standards Telephone Line Open Indication 8/88 Glossary of Mnemonics www.printcopy.info 6-50 Telecopier 7017 / 7017SF...
  • Page 168 P/J 103 Scan Interlock Switch 7-20 P/J 104 Scan Motor 7-20 P/J 106 Wide Original Sensor (W2) 7-20 P/J 107 Document Sensor (W3) 7-20 P/J 109 Nudger Solenoid 7-21 P/J 110 Scan Position Sensor (W4) 7-21 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section7.htm (1 of 2) [28/09/1999 11:42:06]...
  • Page 169 7-21 P/J 123 Video Assembly 7-22 P/J 124 (A) Power Assembly 7-22 P/J 124 (B) Power Assembly 7-22 P/J 201 Video Assembly 7-23 P/J 202 A-Si Sensor 7-23 P/J 202 A-Si Sensor 7-23 www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section7.htm (2 of 2) [28/09/1999 11:42:06]...
  • Page 170 THERMAL HEAD J402 WIDE ORIGINAL J403 DOCUMENT SENSOR J405 SCAN POSITION SENSOR J406 JAM SENSOR J408 LOW PAPER SENSOR J409 WIDE PAPER SENSOR P701 TELEPHONE P901 TELEPHONE TELEPHONE JACK TELEPHONE JACK 12/88 Plug/Jack Locationals, PWB Designations www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 171 P 122 Not used P 107 P 106 P 105 (Not Used) P 102 (Not Used) P 123 P 103 P 101 Figure 1- A0 CNC PWB Plug Jack Locations 7017-350 A 8/88 Plug Jack Locationals www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 172 6/88 Plug Jack Locational www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 173 8/88 Plug Jack Locationals www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 174: Analog Ground

    POWER A0 CNC A2 MAIN A10 COUPLER SUPPLY P124 J124 7017-353 6/88 Analog Ground www.printcopy.info Telecopier 7017 / 7017SF...

  • Page 175: Logic Ground

    POWER SUPPLY A0 CNC A2 MAIN A10 COUPLER P124 J124 A5 MODEM Logic Ground 7017-354 6/88 Logic Ground www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 176 A2 MAIN A8 STORE & FORWARD Logic Ground 7017-354 6/88 Logic Ground www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 177 J 106 J402 WIDE ORIGINAL LOW PAPER SENSOR SENSOR P117 J117 P 107 J 107 J403 J409 DOCUMENT SENSOR WIDE PAPER SENSOR P122 J122 P110 J110 J405 SCAN POSITION SENSOR 7017-355 A 8/88 Logic Ground www.printcopy.info Telecopier 7017 / 7017SF...
  • Page 178 A0 CNC PWB P123 J123 P201 J201 A1 VIDEO (P/O VIDEO ASSEMBLY) P111 J111 A6 CONTROL PANEL PWB P120 J120 P301 J301 THERMAL HEAD P121 J121 P302 J302 7017-356A 12/88 Logic Ground www.printcopy.info 7-10 Telecopier 7017 / 7017SF...

  • Page 179: High Ground

    P124 J124 P119 J119 POWER SUPPLY A0 CNC PWB P120 J120 THERMAL HEAD A2 MAIN PWB A10 COUPLER 7017-357 6/88 High Ground www.printcopy.info Telecopier 7017 / 7017SF 7-11...

  • Page 180: P+5Vdc Power Distribution

    A10 COUPLER P 107 J 107 J403 DOCUMENT SENSOR P114 J114 J406 PRINTER SENSOR P 106 J 106 J402 WIDE ORIGINAL SENSOR P111 J111 A6 CONTROL PANEL PWB 7017-358 A 8/88 P+5 VDC Power Distribution www.printcopy.info 7-12 Telecopier 7017 / 7017SF...

  • Page 181: M+5Vdc Power Distribution

    A2 MAIN POWER A10 COUPLER SUPPLY A5 MODEM P201 P201 P123 J123 A1 VIDEO (P/O VIDEO ASSEMBLY) A8 STORE & FORWARD PWB P120 J120 P301 J301 THERMAL HEAD 7017-359A 12/88 M+5 VDC Power Distribution www.printcopy.info Telecopier 7017 / 7017SF 7-13...

  • Page 182: M+12Vdc Power Distribution

    (P/O VIDEO ASSEMBLY) Note: This diagram A10 COUPLER is placed here for LINE convenience. FILTER A8 STORE & PJ901 FORWARD PWB PJ902 HANDSET LINE CORD TO WALL 7017-360 B 12 /88 M+12 VDC Power Distribution www.printcopy.info 7-14 Telecopier 7017 / 7017SF...
  • Page 183 A2 MAIN PWB P 124 J 124 A10 COUPLER SUPPLY A5 MODEM P201 P201 P 123 J 123 A1 VIDEO (P/O VIDEO ASSEMBLY) A8 STORE & FORWARD PWB 7017-361A 12/88 M-12 VDC Power Distribution www.printcopy.info Telecopier 7017 / 7017SF 7-15...

  • Page 184: M+15Vdc Power Distribution

    POWER A0 CNC PWB P 124 J 124 SUPPLY P 123 J 123 P201 P201 A1 VIDEO (P/O VIDEO ASSEMBLY) 7017-362A 12/88 M+15 VDC Power Distribution www.printcopy.info 7-16 Telecopier 7017 / 7017SF...

  • Page 185: M+24Vdc Power Distribution

    POWER A0 CNC A2 MAIN P124 J124 SUPPLY COUPLER P109 J109 NUDGER SOLENOID P118 J118 P120 J120 P301 J301 THERMAL CUTTER SOLENOID HEAD P119 P119 7017-363 6/88 M+24 VDC Power Distribution www.printcopy.info Telecopier 7017 / 7017SF 7-17...

  • Page 186: P/J 1(A) A2 Main Pwb

    MAIN PTR MOTOR PMTAN MAIN M-12V MAIN PTR MOTOR PMTBP MAIN PTR MOTOR PMTBN MAIN M+12V MAIN M+24V MAIN M+24V MAIN AGND MAIN HGND MAIN HGND MAIN AGND 6/88 P/J 1, P/J 2 (A) www.printcopy.info 7-18 Telecopier 7017 / 7017SF...

  • Page 187: P/J 2 (B) A2 Main Pwb

    MAIN COUPLER MODTX MODEM IRQL COUPLER M+12V MAIN MODEM CABS1H COUPLER AGND MAIN MODEM CABS2H MAIN MODEM PORL MODEM M-12V MODEM MAIN MODEM LGND MAIN MODEM 6/88 P/J 2 (B), P/J 3, P/J 4 www.printcopy.info Telecopier 7017 / 7017SF 7-19...

  • Page 188: P/J 101 Speaker

    OPMBEL OPTION MAIN OPN0L SENSOR MAIN SNDOCH OPTION P+5V OPTION LGND SENSOR LGND OPTION P+5V OPTION LGND OPTION M+12V OPTION LGND OPTION M-12V OPTION LGND 8/88 P/J 6, P/J 101, P/J 103 P/J 1O7 www.printcopy.info 7-20 Telecopier 7017 / 7017SF...

  • Page 189: P/J 109 Nudger Solenoid

    PHB4P LGND MAIN PANEL PNRSTL SENSOR LGND MAIN THLATL PANEL MAIN PINTL SENSOR MAIN SNPB4L MAIN THDTBH PANEL P+5VDC MAIN THRSTL PANEL LGND MAIN RCON0S MAIN RCON1S MAIN RCON2S 8/88 P/J 109 P/J 121 www.printcopy.info Telecopier 7017 / 7017SF 7-21...
  • Page 190 MAIN SCDENL HGND HGND MAIN SCDRQL HGND HGND MAIN SCDTBL HGND HGND MAIN CLK664 HGND HGND M+5VDC LGND M+5VDC LGND M-12VDC MAIN LEDONL M+12VDC LGND M+15VDC LGND M+15VDC LGND 8/88 P/J 123, P/J 124 www.printcopy.info 7-22 Telecopier 7017 / 7017SF...
  • Page 191 P/J 204 A-Si Sensor M+5V CLK664 From SIGNAL SCDTBL SCDRQL SCDENL DAKWRL SHDWRL SC5MSL SMTRQL SDCONL VDMD2H VDMD0H VDMD1H SCMD0H SCMD1H SCMD2H SCMD3H VDTH0H VDTH1H VDTH2H VDTH3H VDTH4H VDTH5H 8/88 P/J 201, P/J 202, P/J 204 www.printcopy.info Telecopier 7017 / 7017SF 7-23...
  • Page 192 8. Store and Forward Option 8. Store and Forward Option Store and Forward Option www.printcopy.info http://xww.xedoc.world.xerox.com/data/XEDOC/Central/Fax/7017/TECH/section8.htm [28/09/1999 11:42:50]...
  • Page 193 Relay send terminal indicates A4 letter recording paper Delayed start capability. The Table 2 indicates the transmit Long original is not available in Store and reduction capability: forward. 6/88 Introduction 8A-4 Telecopier 7017 / 7017SF www.printcopy.info...
  • Page 194 2. Secure A8 to terminal. a. Secure rear of A8 to Power supply. b. Secure front of A8 to RH frame. 3. Apply 7017SF Control Panel label. 6/88 Repair Analysis Procedure, Parts List, Installation Telecopier 7017 / 7017SF 8A-5 www.printcopy.info...

This manual is also suitable for:

Telecopier 7017sf

Table of Contents
