MVE-V11-V13
NOTE
For these models, terminations can be made at either end of the input and output busbars.
A
B
B
C
2/T1
4/T2
1/L1
3/L2
MVE-0070-V11 ~ MVE-0540-V11
MVE-0070-V13 ~ MVE-0540-V13
MVE-0600-V11 ~ MVE-1700-V11
MVE-0600-V13 ~ MVE-1700-V13
6.6
Earth Terminations
Models V02~V06 do not include earth studs.
Models V11~V13 have two 10 mm earth studs, at the rear of each phase arm close to the mounting points. Use only M10 high
tensile grade 8.8 threaded fasteners for all terminations. Use a pre-load torque setting between 28 ~ 30 Nm. Use only Belleville
washers.
A
B
C
D
6/T3
5/L3
A
B
mm (inch)
mm (inch)
88
132
(12.1)
(5.2)
E
E
C
mm (inch)
232
(7.8)
197
(9.1)
For typical values, please consult AuCom
INSTALLATION
D
E
mm (inch)
mm (inch)
1000
378
(39.4)
(14.9)
1100
148
(43.3)
(16.5)
MVE User Manual (710-17074-00G) |
17
