7.11 Monitoring
Logs Menu
The Logs Menu provides information on events, trips and starter performance.
To open the Logs Menu, press ALT then LOGS while viewing the metering screens.
To navigate through the Logs Menu:
•
to open a log, press the
•
to scroll through the entries in each log, press the
•
to view details of a log entry, press the
•
to return to the previous level, press the
•
to close the Logs Menu, press
Trip Log
•
The Trip Log stores details of the eight most recent trips, including the date and time the trip happened. Trip 1 is the most recent
and trip 8 is the oldest stored trip.
To open the Trip Log:
1.
Press ALT then LOGS to open the Logs.
2.
Scroll to Trip Log and press
3.
Use the
and
4.
Use the
and
To close the log and return to the main display, press
Event Log
•
The Event Log stores time-stamped details of the starter's 99 most recent events (actions, warnings and trips), including the date
and time of the event. Event 1 is the most recent and event 99 is the oldest stored event.
To open the Event Log:
1.
Press ALT then LOGS to open the Logs.
2.
Scroll to Event Log and press
3.
Use the
and
To close the log and return to the main display, press
Starter Trip and Event Logger Software
•
The Starter Trip and Event Logger Software allows you to download the trip and event logs from the soft starter, for separate
analysis.
The software is compatible with all AuCom medium voltage soft starters using control software version 1.29 or later.
For further information, or to download the software, visit www.aucom.com.
Logs
button.
button.
button.
repeatedly.
.
buttons to select a trip to view, and press
buttons to scroll through available details.
repeatedly.
.
buttons to select an event to view, and press
repeatedly.
ALT
Alt
Tools
LOGS
and
buttons.
to display details.
to display details.
CONTROLLER
MVE User Manual (710-17074-00G) |
37
