6.5

Power Terminations

Use only M10 high tensile grade 8.8 threaded fasteners for all terminations.
Use a pre-load torque setting between 28 ~ 30 Nm.
Use only Belleville washers.
NOTE
Aluminium busbars must be free from oxide and contaminants, and the connection must be pasted with anti-oxidant
compound.
NOTE
After the phase arm has been installed in the panel, perform an earth bonding test between the mounting frame and
the main earth bus to confirm that the frame is adequately earthed.
MVE-0070~0540, V02 ~ V04
NOTE
For these models, terminations can be made at either end of the input and output busbars.
B B
B B
A
C
1/L1
3/L2
2/T1
4/T2
MVE-0070-V02 ~ MVE-0540-V02
MVE-0070-V03 ~ MVE-0540-V03
MVE-0070-V04 ~ MVE-0540-V04
B B
C
A
D
5/L3
6/T3
A
mm (inch)
mm (inch)
60
(2.4)
(2.5)
E
B
C
mm (inch)
63
126
(5.0)
INSTALLATION
D
E
mm (inch)
mm (inch)
558
315
(22.0)
(12.4)
MVE User Manual (710-17074-00G) |
15
