Inputs
Inputs on Controller
Start (C23, C24) .................................................................................................................................................
Stop (C31, C32)
.................................................................................................................................................
Reset (C41, C42)
Input A (C53, C54) .............................................................................................................................................
Input B (C63, C64) .............................................................................................................................................
Motor thermistor (B4, B5) .................................................................................................................................... Trip point > 3.6 kΩ
....................................................................................................................................................................................................... Reset > 1.6 kΩ
Inputs on power interface board
Bypass readback input (C73, C74)
Fan Fail (C1, C2)
DOL protection activated (C3, C4)
Power supply fail input (C5, C6)
NOTE
All control inputs are potential free. Do not apply external voltage to these inputs.
Outputs
Outputs on Controller
Output Relay A (43, 44) ...................................................................................................................................... Normally Open
Output Relay B (51, 52, 54)
Output Relay C (61, 62, 64) ...................................................................................................................................... Changeover
Analog output (B10, B11)
Ratings of output relays on Controller
..................................................................................................................................................................
................................................................................................................................................................... 6 A @ 250 VAC 15 p.f. 0.3
.................................................................................................................................................................... 10 A @ 30 VDC resistive
Outputs on power interface board
Main contactor (13, 14)
Bypass contactor (23, 24)
Run Output/ PFC (33, 34) .................................................................................................................................. Normally Open
Phase arm power supply control relay output (43, 44)
Environmental
Degree of Protection
Power Assembly
Controller
...........................................................................................................................................................
Operating temperature ........................................................................................ - 10 ˚C to + 60 °C, above + 50 °C with derating
Humidity
......................................................................................................................................... 5%~95% Relative Humidity
Storage temperature
Humidity
......................................................................................................................................... 5%~95% Relative Humidity
Operating Altitude .............................................................................................................
Pollution degree ................................................................................................................................................... Pollution Degree 3
Vibration
............................................................................................................................................ Designed to IEC 60068-2-6-Fc
EMC Emission (Designed to IEC 60947-4-2)
Equipment class (EMC) ........................................................................................................................................................... Class A
Conducted radio frequency emission
..................................................................................................................................................... 0.15 MHz to 0.5 MHz: < 79 dB µV
................................................................................................................................................................. 0.5 to 30 MHz: < 73 dB µV
Radiated radio frequency emission .................................................................................. 0.15 MHz to 30 MHz: < 80-50 dB µV/m
..................................................................................................................................................... 30 to 100 MHz: < 60-54 dB µV/m
.............................................................................................................................................
This product has been designed as Class A equipment. Use of this product in domestic environments may cause radio
interference, in which case the user may be required to employ additional mitigation methods.
...............................................................................................................................................
.................................................................................................................
...............................................................................................................................................
..................................................................................................................
.....................................................................................................................
..................................................................................................................................... Changeover
........................................................................................................................ 0-20 mA or 4-20 mA
..................................................................................................................................... Normally Open
................................................................................................................................. Normally Open
.................................................................................................................................................................. IP00
............................................................................................................................................
................................................................................... 10 kHz to 150 kHz: < 120 - 69 dB µV
................................................................................ Normally Open
0~1000 m, above 1000 m with derating
100 MHz to 2000 MHz: < 54 dB µV/m
MVE User Manual (710-17074-00G) |
SPECIFICATIONS
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
24 VDC, 8 mA approx
10 A @ 250 VAC resistive
IP54/ NEMA 12
- 25 ˚C to + 70 ˚C
9
