8I, 8J, 8K, 8L – Performance Graphs
The MVE has a real-time performance graph to report the behaviour of critical operating parameters.
Parameter 8I Graph Data
Options: Current (% FLC) (default)
Motor Temp (%)
Motor kW (%)
Motor kVA (%)
Motor pf
Voltage (%Mains)
Description: Selects which information the graph will display.
Parameter 8J Graph Timebase
Options: 10 seconds
30 seconds
1 minute (default)
5 minutes
Description: Sets the graph time scale. The graph will progressively replace the old data with new data.
Graph Maximum Adjustment
Parameter 8K
Range: 0% – 600%
Description: Adjusts the upper limit of the performance graph.
Parameter 8L Graph Minimum Adjustment
Range: 0% – 600%
Description: Adjusts the lower limit of the performance graph.
8M – Mains Reference Voltage
Range: 100 – 14000 V
Description: Provides the reference voltage for the analog output and performance graphs.
9 Motor Data-2
The MVE can support two different starting and stopping motor data sets.
To select the secondary motor data set, a programmable input must be configured to parameter set selection (parameters 6A and
6F) and the input must be active when the soft starter receives a start signal.
NOTE
You can only choose which motor data set to use while the soft starter is stopped.
Current as a percentage of motor full load current.
Motor temperature as a percentage of the motor rated current
(calculated by the soft starter's thermal model).
Motor kilowatts. 100% is motor FLC (parameter 1A) multiplied by mains
voltage. Power factor is assumed to be 1.0.
√3 . V . I . pf
FLC
1000
Motor kilovolt amperes. 100% is motor FLC (parameter 1A) multiplied
by mains voltage.
√3 . V . I
FLC
1000
Motor power factor, measured by the soft starter.
The average voltage measured on three phases as a percentage of the
mains voltage.
10 minutes
30 minutes
1 hour
Default: 400%
Default: 0%
Default: 400 V
