CONTROLLER
9A ~ 9E – Secondary Motor Settings
Reserved
Parameter 9A
This parameter is reserved for future use.
Parameter 9B Motor FLC-2
Range: 5 - 1000 A
Description: Sets the secondary motor's full load current.
Reserved
Parameter 9C
This parameter is reserved for future use.
Reserved
Parameter 9D
This parameter is reserved for future use.
Reserved
Parameter 9E
This parameter is reserved for future use.
10 Start/Stop-2
10A ~ 10I – Start/Stop-2
Refer to Start/Stop-1 (parameters 2A~2I) for details.
Start Mode-2
Parameter 10A
Options: Constant Current (default)
Description: Selects the soft start mode.
Parameter 10B Start Ramp-2
Range: 0:01 - 3.00 (minutes:seconds)
Description: Sets the ramp time for current ramp starting (from the initial current to the current limit).
Initial Current-2
Parameter 10C
Range: 50% - 600%
Description: Sets the initial start current level for current ramp starting, as a percentage of motor full load current. Set so
that the motor begins to accelerate immediately after a start is initiated.
If current ramp starting is not required, set the initial current equal to the current limit.
Current Limit-2
Parameter 10D
Range: 50% - 600% FLC
Description: Sets the current limit for constant current and current ramp soft starting, as a percentage of motor full load
current.
Reserved
Parameter 10E
Description: This parameter is reserved for future use.
Kickstart Time-2
Parameter 10F
Range: 0 - 2000 (milliseconds)
Description: Sets the kickstart duration. A setting of 0 disables kickstart.
Parameter 10G Kickstart Level-2
Range: 100% - 700% FLC
Description: Sets the level of the kickstart current.
Stop Mode-2
Parameter 10H
Options: Coast To Stop (default)
TVR Soft Stop
Description: Selects the stop mode.
Stop Time-2
Parameter 10I
Range: 0:00 - 4:00 (minutes:seconds)
Description: Sets the stop time.
58
| MVE User Manual (710-17074-00G)
Default: 100 A
Default: 1 second
Default: 400%
Default: 400%
Default: 0000 milliseconds
Default: 500%
Default: 0 second
