CONTROLLER
Undercurrent
16C
Instantaneous Overcurrent
16D
Current Imbalance
16E
Frequency
16F
Input A Trip
16G
Input B Trip
16H
Motor Thermistor
16I
Starter Communication
16J
Network Communication
16K
16L
Reserved
Battery/Clock
16M
16N
Ground Fault
Reserved
16O
Reserved
16P
Reserved
16Q
Reserved
16R
Reserved
16S
Reserved
16T
16U
Reserved
Undervoltage
16V
Overvoltage
16W
7.15 Parameter Descriptions
1 Motor Data-1
The parameters in Motor Data-1 configure the soft starter to match the connected motor. These parameters describe the motor's
operating characteristics and allow the soft starter to model the motor's temperature.
1A – Motor FLC
Range:
5 - 1200 A
Description:
Matches the starter to the connected motor's full load current. Set to the full load current (FLC) rating shown
on the motor nameplate.
1B – Locked Rotor Time
Range:
0:01 - 2:00 (minutes:seconds)
Description:
Sets the maximum length of time the motor can sustain locked rotor current from cold before reaching its
maximum temperature. Set according to the motor datasheet.
1C – Locked Rotor Current
Range:
400% - 800% FLC
Description:
Sets the locked rotor current of the connected motor, as a percentage of full load current. Set according to the
motor datasheet.
1D – Motor Service Factor
Range:
100% - 120%
Description:
Sets the motor service factor used by the thermal model. If the motor runs at full load current, it will reach
100%. Set according to the motor datasheet.
2 Start/Stop Modes-1
2A – Start Mode
Options:
Constant Current (default)
Description:
Selects the soft start mode.
46
| MVE User Manual (710-17074-00G)
Default:
100 A
Default:
10 seconds
Default:
600%
Default:
105%
