5.10 Power Terminations

NOTE
For personnel safety, the power terminals on models up to EMX3-0105B are protected by snap-off tabs. When using
large cables, it may be necessary to break off these tabs.
NOTE
Some units use aluminium busbars. When connecting power terminations, we recommend cleaning the surface
contact area thoroughly (using an emery or stainless steel brush) and using an appropriate jointing compound to prevent
corrosion.
Use only copper stranded or solid conductors, rated for 75 ºC or higher.
Cable size:
6-50 mm (AWG 10-1/0)
2
Torque: 4 Nm (2.9 ft-lb)
EMX3-0145B
19 Nm (14.0 ft-lb)
8.5 mm
(M8)
19 mm
EMX3-0350B~EMX3-0425B
38 Nm (28.0 ft-lb)
11 mm
(M10)
28 mm
EMX3-0360C~EMX3-0930C
38 Nm (28.0 ft-lb)
10.5 mm
(M10)
32 mm
EMX3-0023B~EMX3-0105B
14 mm (0.55 inch)
EMX3-0170B~EMX3-0220B
38 Nm (28.0 ft-lb)
10.5 mm
(M10)
6 mm
EMX3-0500B~EMX3-1000B
38 Nm (28.0 ft-lb)
11 mm
(M10)
6 mm
13 mm
19 mm 6 mm
13 mm
32 mm
EMX3-1200C~EMX3-1600C
12.5 mm
(M12)
INSTALLATION
Torx T20 x 150
Flat 7 mm x 150
EMX3-0255B
38 Nm (28.0 ft-lb)
11 mm
(M10)
28 mm
EMX3-0255C
38 Nm (28.0 ft-lb)
10.5 mm
(M10)
32 mm
66 Nm (48.7 ft-lb)
51 mm 16 mm
User Manual (710-04840-00M) |
5 mm
6 mm
