Controlling the Scalers

The scalers can be controlled using one or more of the following methods:
Output Standby Mode — Mutes video and sync output to the display device when
no active input signal is detected. This allows the projector or flat-panel display to
automatically enter into standby mode to save energy and enhance lamp or panel life.
Power Save Mode — Conserves energy when not in use.
Picture controls — Includes controls for brightness, contrast, color, tint, and detail, as
well as horizontal and vertical positioning, and sizing.
Automatic 3:2 and 2:2 pulldown detection — Helps maximize image detail and
sharpness for NTSC, PAL, and HDTV 1080i sources that originated from film.
Quad standard, 3D composite video decoding — Provides advanced decoding
of composite NTSC 3.58, NTSC 4.43, PAL, and SECAM for integration into systems
worldwide using a temporal, 3D adaptive comb filter.
User presets — Store optimized image settings to be recalled later.
Internal test patterns — Include a crop pattern, grayscale, color bars, alternating
pixels, blue mode, and audio pink noise for calibration and setup.
Front panel security lockout — Locks out all front panel functions, except for input
selection and volume control. Full controls remain available through Ethernet, USB, or
RS-232 control.
Ethernet monitoring and control — Enables control and proactive monitoring over a
LAN, WAN, or the Internet. An intuitive web interface is included for full configuration of
the device.
Built-in web server — Enables the use of a standard browser for full control and
troubleshooting over an intuitive web interface.
RS-232 control port — Enables the use of serial commands for complete control and
configuration via an integrated control system. Extron products use the SIS, Simple
Instruction Set command protocol, a set of basic ASCII commands that allow for quick
and easy programming.
Front panel USB configuration port — Enables easy configuration without having to
access the rear panel.
Rack-mountable 1U (IN1606 and IN1608) or 2U (IN1608 SA and IN1680 MA), full
rack width metal enclosure
Includes LockIt HDMI cable lacing brackets
Internal universal power supply — The 100-240 VAC, 50-60 Hz, international power
supply provides worldwide power compatibility.
The front panel controls and the on-screen display (OSD) menu.
A computer, a touch screen panel, or any other device that can send and receive
serial communications through the USB, RS-232, or Ethernet port. The Extron Simple
Instruction Set (SIS) is a set of simple keystroke commands that can be used with any
such devices.
Internal web pages provide a web browser-based interface for controlling the switcher
from a computer over a LAN network.
Ethernet control via IP Link, enabling the switcher to be controlled and actively
monitored over a LAN, WAN, or the Internet.
The Extron Product Configuration Software (PCS).
IN1606 and IN1608 Series Scaling Presentation Switcher • Introduction
7
