GTS
5.1.4
Lower part & tank
5.1.4.1 Replacing of tank
Picture 8: Tank
Remove
•
•
•
•
•
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Remove tank cover according to chapter REPLACING OF TANK
COVER.
Remove fresh water hose from tank.
Remove rear panel.
Unscrew charger jack from rear panel.
Unlock battery compartment by removing screws from locking
system.
Open the battery compartment.
Thread out wiring and hoses to the battery compartment.
Close battery compartment.
Edition: V1.00/2010
Technical Manual
5-15
