5.1.2

Squeegee lowering mechanism

5.1.2.1 Replacing of squeegee bracket spring
Picture 2: Squeegee lowering
Remove
•
•
1
2
Remarks
Lift up the rear of machine and incline it to the front to loosen the
tension of the spring.
3
•
4
Mount
•
•
•
Ensure that the slide bearings are proper positioned.
•
•
Service
Apply lubricant locking on the screws (03/103).
15. March 2010
Copyright © 2010, Diversey Inc.
Remove the squeegee from the fixation.
Remove the tool from the brush drive unit.
Remove screws (03/103) from support (03/101).
Put the bracket in working position (down).
Remove one circlip of rear axle.
Remove the rear axle.
Remove pressure spring.
Assemble new pressure spring.
Assemble the rear axle.
Position the circlip on the rear axle.
Move the squeegee bracket to semi transport position.
Assemble the screws.
