Taski swingo 855B Power Technical Manual page 30

GTS
•
•
•
•
•
•
•
Mount (Drilling of hole for tank cover axle)
Assemble the tank cover lock at the end of the sequence.
•
•
•
Make sure that the sealings are nicely positioned.
•
•
•
Remarks
Ensure that the flap is positioned between the tank and the base
plate.
•
•
Remarks
Ensure that the cables are positioned that way, that they can not
be squeezed by the tank cover.
•
•
•
•
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
power electronics).
Remove cable fixation at base plate.
Thread out cables from tank cover.
Close tank cover.
Remove fixation screw of axle on one side.
Push out axle (09/101).
Remove complete cover.
According to what you need to exchange, remove the existing
parts from the tank cover and place it on the new one.
Position the base plate on the new tank cover.
Fix the base plate on the tank cover.
Position the tank cover including base plate correctly on the
tank.
Drill the hole for the tank axle without pressing the tank cover
down onto the tank (drill with 10 mm).
Mount the tank cover axle.
Fix the axle with the screws.
Open tank cover.
Thread in cable to the tank cover.
Fix cables on the base plate.
Connect vacuum motor to the connection block (cable from
power electronics).
Close tank cover and position it on the base plate.
Open tank cover together with base plate.
Use the tank cover support.
Tighten base plate fixation on the LH side.
Tighten base plate fixation on the tank support side (RH).
