Taski swingo 855B Power Technical Manual page 50

GTS
Mount
•
Take care that the belt is positioned correctly.
•
•
Service
Apply adhesive looking on the screws (09/134).
•
•
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Position the new motor/new belt.
Insert the counter head screw.
Position the two other screws.
Tension the belt.
Tighten all screws.
Complete assembling according to the chapter REPLACING OF
PULLEY BELT.
Complete assembling according to the chapter REPLACING OF
BRUSH BELT.
Complete assembling according to the chapter REPLACING OF
BRUSH DRIVE UNIT.
Edition: V1.00/2010
Technical Manual
5-29
