5.1.1.5 Replacing of tank cover

Picture 7: Tank cover
Remove
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Picture 1: Base plate
•
15. March 2010
Copyright © 2010, Diversey Inc.
Unscrew dashboard fixation.
Remove dashboard and disconnect all cables.
Remove screws of handle cover.
Disconnect wires of external hour counter from the cover or
the hour counter depending on the setup.
Remove handle cover.
Unscrew screws of throttle lever bracket.
Thread out hall sensor ribbon cable and remove the complete
throttle lever system.
Unscrew handle fixation to the tank cover (02/103) and (02/
107).
Remove handle from tank cover.
Unscrew and remove rear panel.
Open the tank cover.
Loosen the screw on the tank cover on the support side (RH).
Loosen the screw on the other side (LH).
Close the tank cover.
Open the tank cover without base plate.
Disconnect vacuum motor cable at connection block (cable to
