GTS
5.1.3
Squeegee
Picture 3: Squeegee
5.1.3.1 Replacing of fixation spring
Picture 4: Offset fixation
Remove
•
•
•
Mount
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Unscrew the 2 screws of the offset fixation.
Remove the offset and the spring.
Remove the spring from the offset.
Assemble the new spring on the offset.
Assemble the offset and the spring on the squeegee.
Mount the screws of the offset.
Edition: V1.00/2010
Technical Manual
5-12
