Brush Drive Unit - Taski swingo 855B Power Technical Manual

GTS
5.1.6

Brush drive unit

5.1.6.1 Replacing of brush drive unit
Picture 15: Brush drive replacing
Remove
•
•
•
•
•
•
•
•
•
•
•
•
Make sure that you hold the brush drive unit firmly.
•
Mount
•
•
•
Adjustment
Default setting:
Eccentric disc (07/122): Position 4
Eccentric shaft (07/110): Position 4
15. March 2010
Copyright © 2010, Diversey Inc.
Unlock battery compartment by removing screws from locking
system.
Open battery compartment.
Put the brush drive unit in cleaning position.
Unscrew brush housing fixation screws.
Remove the brush housing from the brush drive unit.
Disconnect pump wiring.
Disconnect the fresh water hose from the pump.
Disconnect the brush motor wires from power electronics.
Remove self locking nuts (M8) on LH and RH from the bolts,
holding brush drive unit to the cradle.
Remove self locking nut (M6) at eccentric disc at the RH.
Remove the eccentric disc.
Remove the bolt and eccentric shaft.
Pivot the complete brush drive unit out.
Position the brush drive unit to the cradles.
Position the bolt and the eccentric shaft.
Position the eccentric disc.
Edition: V1.00/2010
Technical Manual
5-22
