Taski swingo 855B Power Technical Manual page 28

GTS
Remarks
Ensure that the vacuum motor sealings are proper positioned
before assembling the protection plate back.
•
Remarks
Ensure that the turn protection is placed (spin protection).
•
•
•
•
•
•
•
•
Tighten the fixation rubbers smoothly.
Remarks
Check at the end if the vacuum motor top sealing is positioned
properly, therefore unscrew and remove the dashboard and check.
15. March 2010
Copyright © 2010, Diversey Inc.
Position and tighten the vacuum motor protection plate
fixation.
Assemble capacitor.
Position top sealing of vacuum motor.
Connect vacuum motor wires to connection block.
Close tank cover and position it on the base plate.
Open tank cover together with base plate.
Use the tank cover support.
Tighten base plate fixation on the LH side.
Tighten base plate fixation on the tank support side (RH).
Edition: V1.00/2010
Technical Manual
5-7
