Picture 3: Hall sensor positioning
•
•
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Place and tighten screw of mechanic hall sensor compl.
Thread in the hall sensor compl. ribbon cable.
Connect hall sensor compl. ribbon cable to the dashboard.
Position dashboard and fix it with the 5 screws.
Complete assembling according to the chapter REPLACING OF
MICROSWITCH.
Edition: V1.00/2010
Technical Manual
5-4
