Remarks
Check at the end if the vacuum motor top sealing is positioned
properly, therefore unscrew and remove the dashboard and check.
•
•
Adjustment
Adjust the tank cover lock and ensure a proper opening and closing
of the tank cover.
•
•
•
•
•
•
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Open tank cover.
Assemble tank cover lock.
Mount the rear panel.
Assemble handle on the tank cover with the 7 screws.
Position the complete throttle lever system.
Thread in the hall sensor cable to the dashboard.
Fix the throttle lever bracket with the screws.
Position wires on the external hour counter or on the handle
cover, depending on the setup.
Mount the handle cover.
Connect wires to dashboard.
Assemble dashboard on the tank cover.
