Parameter Mapping Lists
VLT 5000 series
Parameter 127 DC brake cut-in
frequency
Range
0.0 (Off) – f
(par. 202)
max
Table 5.46 Conversion of Parameter 127
VLT 5000 series
Parameter 128 Motor thermal
protection
Options
[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] ETR warning 1
[4] ETR trip 1
[5] ETR warning 2
[6] ETR trip 2
[7] ETR warning 3
[8] ETR trip 3
[9] ETR warning 4
[10] ETR trip 4
Table 5.47 Conversion of Parameter 128
VLT 5000 series
Parameter 129 External motor fan
Options
[0] No
[1] Yes
Table 5.48 Conversion of Parameter 129
VLT 5000 series
Parameter 130 Start frequency
Range
0.0 – 10.0 Hz
Table 5.49 Conversion of Parameter 130
VLT 5000 series
Parameter
131 Initial voltage
Table 5.50 Conversion of Parameter 131
VLT 5000 series
Parameter
145 Minimum DC brake time
Table 5.51 Conversion of Parameter 132
MG37E102
Operating Instructions
FC 302 series
2-04 DC Brake Cut In
Speed [Hz]
0.0 (Off) – f
(par. 414)
max
FC 302 series
1-90 Motor Thermal
Protection
[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] ETR warning 1
[4] ETR trip 1
[5] ETR warning 2
[6] ETR trip 2
[7] ETR warning 3
[8] ETR trip 3
[9] ETR warning 4
[10] ETR trip 4
FC 302 series
1-91 Motor External Fan
[0] No
[1] Yes
FC 302 series
1-75 Start Speed [Hz]
0.0 – 500 Hz P.U depending
FC 302 series
Not converted
FC 302 series
Not converted
Danfoss A/S © Rev. 2014-03-06 All rights reserved.
®
5.3 VLT
5000 Parameter Group 2
VLT 5000 series
Parameter 200 Output Frequency Range/
Direction
Options
[0] Only clockwise, 0 – 132 Hz
[1] Both directions, 0 – 132 Hz
[2] Only clockwise, 0 – 1000 Hz
[3] Both directions, 0 – 1000 Hz
[4] Only counter clockwise, 0 –
132 Hz
[5] Only counter clockwise, 0 –
1000 Hz
Table 5.52 Conversion of Parameter 200
VLT 5000 series
Parameter 201 Output frequency
low limit
Range
0.0 – par. 202 F
max
Table 5.53 Conversion of Parameter 201
VLT 5000 series
Parameter 202 Output frequency
high limit
Range
0.0 – 132/1000 Hz
Table 5.54 Conversion of Parameter 202
VLT 5000 series
Parameter 203 Reference/feedback area 3-00 Reference Range
Options
[0] Min – Max
[1] - Max - +Max
Table 5.55 Conversion of Parameter 203
VLT 5000 series
Parameter
204 Minimum
reference
Range
-100,000.000 – par.
205 Ref
max
Table 5.56 Conversion of Parameter 204
FC 302 series
4-10 Motor Speed
Direction
[0] Clockwise
[2] Both directions
[0] Clockwise
[2] Both directions
[1] Counter
clockwise
[1] Counter
clockwise
FC 302 series
4-12 Motor Speed Low
Limit [Hz]
0 – par. 414 F
[Hz]
max
FC 302 series
4-14 Motor Speed High
Limit [Hz]
4-19 Max Output Frequency
0 – 1000 Hz
FC 302 series
[0] Min – Max
[1] - Max - +Max
FC 302 series
3-02 Minimum
Reference
-100,000.000 – par.
3-03 Ref
max
19
5
5
