Parameter Mapping Lists
VLT 5000 series
Parameter 323, 326
Range [22] Ready, no
thermal warning
[23] Ready - remote
control - no thermal
warning
[24] Ready – mains
voltage within range
[25] Reversing
[26] Bus OK
[27] Torque limit
and stop
[28] Brake, no brake
warning
[29] Brake ready, no
fault
[30] Brake fault
[31] Relay 123
[32] Mechanical
brake control
[33] Control word
bit 11/12
[34] Extended
mechanical brake
control
[35] Safety Interlock
Table 5.114 Conversion of Parameters 323 to 326
VLT 5000 series
Parameter 324 Relay 01, ON delay
Range 0.00 – 600.00 sec
Table 5.115 Conversion of Parameter 324
VLT 5000 series
Parameter 325 Relay 01, OFF delay
Range 0.00 – 600.00 s
Table 5.116 Conversion of Parameter 325
VLT 5000 series
Parameter 327 Pulse reference, max.
freq
Range 100 – 65000 Hz
Table 5.117 Conversion of Parameter 327
MG37E102
Operating Instructions
FC 302 series
5-40 Function Relay
Par. 5-40 = [22] Ready,no
thermal W
Par. 5-40 = [23] Remote, ready,
no TW
Par. 5-40 = [24] Ready, Voltage
OK
Par. 5-40 = [25] Reverse
Par. 5-40 = [26] Bus OK
Par. 5-40 = [27] Torque limit &
stop
Par. 5-40 = [28] Brake, no
brake warning
Par. 5-40 = [29] Brake ready,
no fault
Par. 5-40 = [30] Brake fault
(IGBT)
Par. 5-40 = [31] Relay 123
Par. 5-40.0 = [32] Mech brake
ctrl
Par. 1-72 = [5] VVC+/Flux
Par. 5-40 = [36] Control word
bit 11
Par. 5-40.1 = [37] Control word
bit 12
Par. 5-40.0 = [32] Mech brake
ctrl
Par. 1-72 = [5] VVC+/Flux
Not supported
FC 302 series
5-41 On Delay, Relay
0.01 – 600.00 sec
FC 302 series
5-42 Off Delay, Relay
0.01 – 600.00 s
FC 302 series
5-51 Term. 29 High
Frequency
0 – 110000 Hz
Danfoss A/S © Rev. 2014-03-06 All rights reserved.
VLT 5000 series
Parameter 328 Pulse feedback, max. freq
Range 100 – 65000 Hz
Table 5.118 Conversion of Parameter 328
VLT 5000 series
Parameter 329 Encoder feedback
pulse/rev.
Range 1 – 4096 pulses
Table 5.119 Conversion of Parameter 329
VLT 5000 series
Parameter 330 Freeze ref. /output function
Table 5.120 Conversion of Parameter 330
VLT 5000 series
Parameter 345 Encoder loss
timeout
Range 0.0 – 60.0 s
Table 5.121 Conversion of Parameter 345
VLT 5000 series
Parameter 346 Encoder loss
function
Range [0] Off
[1] Freeze output
frequency
[3] Jog
[4] Max speed
[5] Stop and trip
[7] Select setup 4
Table 5.122 Conversion of Parameter 346
VLT 5000 series
Parameter 357 Term. 42, Output
min. scale
Range 0 – 100%
Table 5.123 Conversion of Parameter 357
VLT 5000 series
Parameter 358 Term. 42, Output
max. scale
Range 0 – 500%
Table 5.124 Conversion of Parameter 358
VLT 5000 series
Parameter 359 Term. 45, Output
min. scale
Range 0 – 100%
Table 5.125 Conversion of Parameter 359
FC 302 series
5-56, 5-50, 5-55
0 – 110000 Hz
FC 302 series
5-70 Term 32/33 Pulses Per
Revolution
1 – 4096 pulses
FC 302 series
Not converted
FC 302 series
4-32 Motor Feedback Loss
Timeout
0.00 – 60.00 s
FC 302 series
4-30 Motor Feedback Loss
Function
[0] Disable
[4] Freeze output
frequency
[3] Jog
[5] Max speed
[11] Stop and trip
[10] Select setup 4
FC 302 series
6-51 Terminal 42 Output
Min Scale
0 – 200%
FC 302 series
6-52 Terminal 42 Output
Max Scale
0 – 200%
FC 302 series
6-61 Terminal X30/8 Min.
Scale
0 – 200%
29
