Parameter Mapping Lists
®
5.10 VLT
5000 Parameter Group 9
VLT 5000 series
Parameter
904 PPO type select for DP
Table 5.274 Conversion of Parameter 904
VLT 5000 series
Parameter 915 PCD config write
Options
[0] None
[204] Minimum Reference [302] Minimum Reference
[205] Maximum
Reference
[219] Catch up/slow
Down Value
[207] Ramp 1 Ramp up
Time
[208] Ramp 1 Ramp
Down Time
[209] Ramp 2 Ramp up
Time
[210] Ramp 2 Ramp
down Time
[211] Jog Ramp Time
[212] Quick Stop Ramp
Time
[201] Motor Low Limit
[Hz]
[202] Motor High Limit
[Hz]
[221] Torque Limit Motor
Mode
[222] Torque Limit
Generator Mode
[509] Bus Jog 1 Speed
[510] Bus Jog 2 Speed
Comments VLT
®
5000 supports more write signals. If a not-
supported signal is written then the corresponding
signal is set to [0] None.
Table 5.275 Conversion of Parameter 915
MG37E102
Operating Instructions
FC 302 series
Not converted
FC 302 series
9-15 PCD Write Configu-
ration
[0] None
[203] Maximum Reference
[312] Catch up/slow
Down Value
[341] Ramp 1 Ramp up
Time
[342] Ramp 1 Ramp
Down Time
[351] Ramp 2 Ramp up
Time
[352] Ramp 2 Ramp
down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp
Time
[412] Motor Speed Low
Limit [Hz]
[414] Motor Speed High
Limit [Hz]
[416] Torque Limit Motor
Mode
[417] Torque Limit
Generator Mode
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
Danfoss A/S © Rev. 2014-03-06 All rights reserved.
VLT 5000 series
Parameter 916 PCD config read
Options
[0] None
[538] Alarm word
[540] Warning word
[541] Ext. status word
[600] Operating hours
[601] Running hours
[602] kWh Counter
[539] Control word
[516] Reference [Unit]
[515] Reference %
[534] Status word
[522] Power [kW]
[523] Power [HP]
[524] Motor voltage
[518] Motor frequency
[520] Motor current
[557] Motor RPM
[526] Motor thermal
[521] Torque
[525] DC link voltage
[536] Brake energy/s
[535] Brake energy/2 min [1633] Brake energy/2 min
[537] Heat sink temp.
[527] Inverter Thermal
[533] External reference
[532] Pulse reference
[517] Feedback [Unit]
[528] Digital input
[529] Analog input 53
[530] Analog input 54
[531] Analog input 60
Table 5.276 Conversion of Parameter 916
VLT 5000 series
Parameter
918 Station address
Range
0 - 63
Table 5.277 Conversion of Parameter 918
VLT 5000 series
Parameter
927 Parameter edit
Options
[0] Disable
[1] Enable
Table 5.278 Conversion of Parameter 927
FC 302 series
9-16 PCD Read Configu-
ration
[0] None
[1472] VLT Alarm Word
[1473] VLT Warning Word
[1474] VLT Ext. status
Word
[1500] Operating hours
[1501] Running hours
[1502] kWh Counter
[1600] Control word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status word
[1610] Power [kW]
[1611] Power [HP]
[1612] Motor voltage
[1613] Motor frequency
[1614] Motor current
[1617] Motor speed
[1618] Motor thermal
[1622] Torque %
[1630] DC link voltage
[1632] Brake energy/s
[1634] Heat sink temp.
[1635] Inverter Thermal
[1650] External reference
[1651] Pulse reference
[1652] Feedback [Unit]
[1660] Digital input
[1662] Analog input 53
[1664] Analog input 54
[1664] Analog input 54
FC 302 series
10-02 MAC ID
0 - 63
FC 302 series
9-27 Parameter Edit
[0] Disable
[1] Enable
41
5
5
