Operating Guide
VLT® FCD 300 PROFIBUS Converter MCA 117
VLT® Decentral Drive FCD 300 and VLT® Decen-
tral Drive FCM 300

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VLT MCA 117 and is the answer not in the manual?

Questions and answers

Related Manuals for Danfoss VLT MCA 117

Summary of Contents for Danfoss VLT MCA 117

  • Page 1 Operating Guide VLT® FCD 300 PROFIBUS Converter MCA 117 VLT® Decentral Drive FCD 300 and VLT® Decen- tral Drive FCM 300...

  • Page 3: Table Of Contents

    FCD 300 Parameter Group 2 FCD 300 Parameter Group 3 FCD 300 Parameter Group 4 FCD 300 Parameter Group 5 FCD 300 Parameter Group 6 FCD 300 Parameter Group 8 FCD 300 Parameter Group 9 Danfoss A/S © 2019.11 AQ289550754901en-000101 / | 3...
  • Page 4 Operating Guide | VLT® FCD 300 PROFIBUS Converter MCA 117 Contents 6 Troubleshooting Troubleshooting Hints 7 Appendix Abbreviations Conventions 4 | Danfoss A/S © 2019.11 AQ289550754901en-000101 /...

  • Page 5: Introduction

    Detailed information including the full range of setup options and diagnosis tools is found in: • 5 Parameter Mapping Lists ® is a registered trademark for Danfoss A/S. 1.2 Additional Resources The following manuals may be helpful when installing the VLT® FCD 300 PROFIBUS Converter MCA 117: •...

  • Page 6: Product Overview

    Observe local rules and regulations when replacing a drive in an existing installation. 1.4.2 Hardware • The VLT® FCD 300 PROFIBUS Converter MCA 117 supports VLT® Decentral Drive FCD 302 only. • There is no support for PROFIBUS FMS networks. 6 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 7: Performance

    After initialization of the FCD 302, most parameters are set to match the factory settings of the FCD 300/FCM 300 parameters. N O T I C E LINKED SETUPS To synchronize changes made with a running motor, ensure that setups are linked. Link the setups in parameter 0-12 This Setup Linked to. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 7...

  • Page 8: Safety

    AC drives contain high voltage when connected to AC mains input, DC supply, or load sharing. Failure to perform installation, start-up, and maintenance by qualified personnel can result in death or serious injury. Only qualified personnel must perform installation, start-up, and maintenance. 8 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 9 Contact with rotating shafts and electrical equipment can result in death or serious injury. Ensure that only trained and qualified personnel perform installation, start-up, and maintenance. Ensure that electrical work conforms to national and local electrical codes. Follow the procedures in this guide. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 9...
  • Page 10 An internal failure in the drive can result in serious injury when the drive is not properly closed. Ensure that all safety covers are in place and securely fastened before applying power. 10 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 11: Installation

    Power cable terminals are 1:1 compatible between VLT® Decentral Drive FCD 300/VLT® DriveMotor FCM 300 and the VLT® Decentral Drive FCD 302. If shielded cables are used, ensure that the shield is mounted as stated in the VLT® Decentral Drive FCD 302 Operating Guide. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 11...
  • Page 12 [32] Mech Brake Ctrl. In the FCD 302, it is not possible to enable mechanical brake control and use relay 2 for another purpose. FCD 300 FCM 300 FCD 302 Mechanical brake Illustration 3: Mechanical Brake Connection 12 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 13: Control Signal Connectors

    VLT® Decentral Drive FCD 302 Operating Guide. The FCD 300 reads the digital inputs every 12 ms whereas the FCD 302 reads the digital inputs every 1 ms. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 13...
  • Page 14 60 in the FCD 302. If analog input 54 in the FCD 302 is not used for motor thermistor, this input can be configured to provide the functionality of output 60 in the FCD 300. 14 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 15 S101 to S104 of the FCD 300 are not needed in the FCD 302 PROFIBUS interface. The Termination of the PROFIBUS line is done via the PROFIBUS termination switch. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 15...

  • Page 16: Emc Precautions

    This ensures a low ohmic path for high-frequency noise that otherwise would have been added to the shield of the PROFIBUS cable, causing disturbance of the communication. N O T I C E Observe relevant national and local regulations, for example, regarding protective-earth connection. 16 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 17 Installation Operating Guide | VLT® FCD 300 PROFIBUS Converter MCA 117 90° 1 PROFIBUS cable 2 90° intersection 3 ≥200 mm (≥7.9 in) Illustration 12: EMC-correct Installation Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 17...

  • Page 18: Configuring The System

    Switch off the power supply before changing the hardware switches. N O T I C E The address change comes into effect at the next power-up and can be read in parameter 9-18 Node Address. 18 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 19 Setting the PROFIBUS Address via Hardware Switches Table 2: Hardware Switch Settings VLT® Decentral Drive FCD 300 VLT® Decentral Drive FCD 302 Switch Address – – Example: – – – – – – Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 19...

  • Page 20: Profibus Address Set Via Parameter Or Ssa Command

    For more information, refer to 6.1 Troubleshooting Hints. 4.5 LED Behavior WARNING ALARM ST/MS LA1/NS1 LA2/NS2 Illustration 14: Overview of LEDs Table 3: Bicolored LEDs LED label Description LA1/NS1 Network status 20 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 21 LA2/NS2 Not used Table 4: Net Status, ST/MS State Description Power on Red: Solid red The option is defect. Contact Danfoss. Green: Flashing The option is OK. green Baud rate search Green: Flashing Searching for the baud rate. Check the connection green to the master if the option stays in this state.

  • Page 22: Factory Settings

    Parameter 3-11 Jog Speed [Hz] 10.0 Hz Parameter 3-16 Reference Resource 2 [0] No function Parameter 3-19 Jog Speed [RPM] 300 RPM Parameter 4-13 Motor Speed High Limit [RPM] 3960 RPM 22 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 23 Parameter 8-54 Reversing Select [0] Digital input Parameter 8-90 Bus Jog 1 Speed 300 RPM Parameter 8-91 Bus Jog 2 Speed 300 RPM Parameter 14-03 Overmodulation [0] Off Parameter 14-11 Mains Voltage at Mains Fault Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 23...
  • Page 24 Parameter 14-21 Automatic Restart Time Parameter 14-32 Current Lim Ctrl, Filter Time Parameter 30-84 Process PID Proportional Gain 0.010 PROFIBUS-specific parameters Parameter 9-71 PROFIBUS Save Data Values [1] Store All Setups 24 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 25: Parameter Mapping Lists

    FCD 302 series Parameter 003 Local Reference Not converted 5.1.4 Conversion of Parameter 004 Active Set-up Table 11: Parameter 004 FCD 300 series FCD 302 series Parameter 004 Active Set-up 0-10 Active Set-up Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 25...
  • Page 26 [3] Copy to 3 from # [9] Copy to ALL from # [4] Copy to 4 from # [9] Copy to ALL from # [5] Copy to ALL from # [9] Copy to ALL from # 26 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 27 FCD 302 series Parameter 009 Display Line 0-23 Display Line 2 010 Display Line 0-20 Display Line 1.1 011 Display Line 0-21 Display Line 1.2 012 Display Line 0-22 Display Line 1.3 Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 27...
  • Page 28 [29] Warning word 2 [hex] – [30] Com. Option warning [hex] [953] Com. Option warning [hex] [31] RPM [min] [1617] Speed RPM [min] [32] RPM x scaling [min] [1609] Custom readout 28 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 29 [1] Enable – 5.1.14 Conversion of Parameter 017 Local Reset of Trip Table 21: Parameter 017 FCD 300 series FCD 302 series Parameter 017 Local Reset of Trip 0-43 [Reset] Key on LCP Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 29...
  • Page 30 Parameter 020 Hand Operation Not converted 5.1.18 Conversion of Parameter 024 User Quick Menu Table 25: Parameter 024 FCD 300 series FCD 302 series Parameter 024 User Quick Menu Not converted 30 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 31: Fcd 300 Parameter Group

    Parameter 1-01: [1] VVC 5.2.2 Conversion of Parameter 101 Torque Characteristic Table 29: Parameter 101 FCD 300 series FCD 302 series Parameter 101 Torque Characteristic 1-03 Torque Characteristics Overload Mode VT Level Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 31...
  • Page 32 Parameter 1-04: [0] High 5.2.3 Conversion of Parameter 102 Motor Power Table 30: Parameter 102 FCD 300 series FCD 302 series Parameter 102 Motor Power 1-20 Motor Power [kW] Range 0.18–4.0 kW 0.09–5.5 kW 32 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 33 107 Automatic Motor Tuning (AMT) 1-29 Automatic Motor Adaptation (AMA) Options [0] Adaptation Off [0] Off [1] Adaptation On, Rs and Xs [1] Enable Complete AMA [2] Adaptarion On, Rs [2] Enable Reduced AMA Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 33...
  • Page 34 Not converted 5.2.13 Conversion of Parameter 120 Start Delay Table 40: Parameter 120 FCD 300 series FCD 302 series Parameter 120 Start Delay 1-71 Start Delay Range 0.0–10.0 s 0.0–10.0 s 34 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 35 5.2.17 Conversion of Parameter 126 DC Braking Time Table 44: Parameter 126 FCD 300 series FCD 302 series Parameter 126 DC Braking Time 2-02 DC Braking Time Range 0.0–60.0 s 0.0–60.0 s Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 35...
  • Page 36 Range 0.0–10.0 Hz 0.0–500 Hz, depending on unit 5.2.21 Conversion of Parameter 131 Initial Voltage Table 48: Parameter 131 FCD 300 series FCD 302 series Parameter 131 Initial Voltage Not converted. 36 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 37 -500 to +500% 5.2.27 Conversion of Parameter 137 DC Hold Voltage Table 54: Parameter 137 FCD 300 series FCD 302 series Parameter 137 DC Hold Voltage 2-00 DC Hold Current Range 0–100% 0–160% Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 37...
  • Page 38 0.04–400.00 Ω 5.2.32 Conversion of Parameter 144 Gain AC Brake Table 59: Parameter 144 FCD 300 series FCD 302 series Parameter 144 Gain AC Brake 2-16 AC Brake Max. Current Range 1.00–1.50 38 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 39: Fcd 300 Parameter Group

    Table 63: Parameter 201 FCD 300 series FCD 302 series Parameter 201 Output Frequency Low Limit 4-12 Motor Speed Low Limit [Hz] Range 0.0 to parameter 202, f 0 to parameter 4-14, f [Hz] Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 39...
  • Page 40 6-15 Terminal 53 High Ref./Feedb. Value 6-25 Terminal 54 High Ref./Feedb. Value 5-53 Term. 29 High Ref./Feedb. Value 5-58 Term. 33 High Ref./Feedb. Value Range Parameter 204, Ref to 100,000.000 Parameter 3-02 Ref to 100,000.000 40 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 41 Parameter 3-48: 25% Parameter 3-50: [2] S-ramp Const Time Parameter 3-55: 1% Parameter 3-56: 25% Parameter 3-57: 1% Parameter 3-58: 25% Parameter 3-82: [2] S-ramp Const Time Parameter 3-83: 1% Parameter 3-84: 25% Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 41...
  • Page 42 Parameter 3-48: 50% Parameter 3-50: [2] S-ramp Const Time Parameter 3-55: 50% Parameter 3-56: 50% Parameter 3-57: 50% Parameter 3-58: 50% Parameter 3-82: [2] S-ramp Const Time Parameter 3-83: 50% Parameter 3-84: 50% 42 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 43 5.3.9 Conversion of Parameter 208 Ramp Down Time 1 Table 70: Parameter 208 FCD 300 series FCD 302 series Parameter 208 Ramp Down Time 1 3-42 Ramp 1 Ramp Down Time Range 0.05–3600.00 s 0.01–3600.00 s Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 43...
  • Page 44 5.3.14 Conversion of Parameter 213 Jog Frequency Table 75: Parameter 213 FCD 300 series FCD 302 series Parameter 213 Jog Frequency 3-11 Jog Speed [Hz] Range 0.0 to parameter 202 0.0 to parameter 4-14 44 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 45 5.3.19 Conversion of Parameter 218 Preset Reference 4 Table 80: Parameter 218 FCD 300 series FCD 302 series Parameter 218 Preset Reference 4 3-10 Preset Reference Range -100.00 to +100.00% -100.00 to +100.00% Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 45...
  • Page 46 Table 85: Parameter 225 FCD 300 series FCD 302 series Parameter 225 Warning Low Frequency 4-52 Warning Speed Low 2-22 Activate Brake Speed [Hz] Range 0.0 to parameter 226 0.0 to parameter 4-53 46 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 47 Table 90: Parameter 230 FCD 300 series FCD 302 series Parameter 230 Frequency Bypass 1 4-61 Bypass Speed From [Hz] 4-63 Bypass Speed To [Hz] Range 0 to parameter 200 0 to parameter 4-14 Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 47...

  • Page 48: Fcd 300 Parameter Group

    303 Terminal 19 Input 5-11 Terminal 19 Input 304 Terminal 27 Input 5-12 Terminal 27 Input 305 Terminal 29 Input 5-13 Terminal 29 Input 307 Terminal 33 Input 5-15 Terminal 33 Input 48 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 49 Parameter 3-15 Reference Resource 1 set to [1] Analog Input 53 [2] Feedback Parameter 3-15 Reference Resource 1 set to [1] Analog Input 53 Parameter 7-00 Speed PID Feedback Source set to [6] Analog Input 53. Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 49...
  • Page 50 The HW switch S202 for analog input 54 must be set to current (ON). 5.4.6 Conversion of Parameter 315 Terminal 60, Min. Scaling Table 97: Parameter 315 FCD 300 series FCD 302 series Parameter 315 Terminal 60, Min. Scaling 6-22 Terminal 54 Low Current 50 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 51 [5] Stop and Trip [5] Stop and Trip 5.4.10 Conversion of Parameter 319 Terminal 42, Output Table 101: Parameter 319 FCD 300 series FCD 302 series Parameter 319 Terminal 42, Output 650 Terminal 42 Output Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 51...
  • Page 52 [8] Run At Reference, Nor Warning Parameter 5-40 = [8] Run On Ref/No Warn [9] Alarm Parameter 5-40 = [9] Alarm [10] Alarm Or Warning Parameter 5-40 = [10] Alarm Or Warning 52 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 53 [35] Safety Interlock Not supported 5.4.12 Conversion of Parameter 327 Pulse Reference, Max. Freq Table 103: Parameter 327 FCD 300 FCD 302 Parameter 327 Pulse Reference, Max. Freq 5-51 Term. 29 High Frequency Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 53...
  • Page 54 [55] Pulse Output Parameter 5-63 = Motor Current [29] Pulse Power [55] Pulse Output Parameter 5-63 = 5-63 = Power [30] Pulse Temperature Not supported [31] Control Word Bit 12 Not supported 54 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 55 5.4.18 Conversion of Parameter 349 Speed Compensated Delay Table 109: Parameter 349 FCD 300 series FCD 302 series Parameter 349 Speed Compensated Delay 1-85 Precise Stop Speed Compensation Delay Range 0–100 ms 0–100 ms Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 55...

  • Page 56: Fcd 300 Parameter Group

    5.5.3 Conversion of Parameter 406 Automatic Restart Time Table 112: Parameter 406 FCD 300 series FCD 302 series Parameter 406 Automatic Restart Time 14-21 Automatic Restart Time Range 0–10 s 0–600 s 56 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 57 5.5.6 Conversion of Parameter 413 Overmodulation Function Table 115: Parameter 413 FCD 300 series FCD 302 series Parameter 413 Overmodulation function 14-03 Overmodulation Function Options [0] Off [0] Off [1] On [1] On Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 57...
  • Page 58 [9] Unit s/h Not supported [10] °C [60] °C [11] Pa [72] Pa [12] l/s [20] l/s [13] m [23] m [14] l/min [21] l/min [15] m /min [24] m /min 58 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 59 5.5.10 Conversion of Parameter 417 Speed PID Proportional Gain Table 119: Parameter 417 FCD 300 series FCD 302 series Parameter 417 Speed PID Proportional Gain 7-02 Speed PID Proportional Gain Data range 0.000–0.150 0.000–1.000 Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 59...
  • Page 60 5.5.15 Conversion of Parameter 422 U0 Voltage at 0 Hz Table 124: Parameter 422 FCD 300 series FCD 302 series Parameter 422 U0 Voltage at 0 Hz 1-55 U/f Characteristic - U Data range 0.0–parameter 103 0.0–1000.0 V 60 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 61 5.5.20 Conversion of Parameter 427 U3 Voltage Table 129: Parameter 427 FCD 300 series FCD 302 series Parameter 427 U3 Voltage 1-55 U/f Characteristic - U Data range 0.0–parameter 103 0.0–1000.0 V Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 61...
  • Page 62 5.5.25 Conversion of Parameter 440 Process PID Proportional Gain Table 134: Parameter 440 FCD 300 series FCD 302 series Parameter 440 Process PID Proportional Gain 7-33 Process PID Proportional Gain Data range 0.00–10.00 0.00–10.00 62 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 63 444 Process PID Lowpass Filter Time Not supported 5.5.30 Conversion of Parameter 445 Flying Start Table 139: Parameter 445 FCD 300 series FCD 302 series Parameter 445 Flying Start 1-73 Flying Start Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 63...
  • Page 64 455 PID Control Range Not supported 5.5.34 Conversion of Parameter 455 Frequency Range Monitor Table 143: Parameter 455 FCD 300 series FCD 302 series Parameter 455 Frequency Range Monitor Not supported 64 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 65: Fcd 300 Parameter Group

    501 Baud Rate 8-32 FC Port Baud Rate Options [0] 300 Not supported [1] 600 Not supported [2] 1200 Not supported [3] 2400 [0] 2400 [4] 4800 [1] 4800 [5] 9600 [2] 9600 Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 65...
  • Page 66 8-91 Bus Jog 2 Speed Range 0.0–parameter 202 0.0–parameter 4-13 5.6.6 Conversion of Parameter 512 Telegram Profile Table 150: Parameter 512 FCD 300 series FCD 302 series Parameter 512 Telegram Profile 8-10 Control Word Profile 66 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 67 Parameter 8-14[11] = [07] Ramp Bit 0 Parameter 8-14[15]=[05] Relay 1 5.6.7 Conversion of Parameter 513 Bus Time Interval Table 151: Parameter 513 FCD 300 series FCD 302 series Parameter Bus Time Interval Not converted Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 67...
  • Page 68 FCD 302 series Parameter 518 Frequency 16-13 Frequency 5.6.13 Conversion of Parameter 519 Frequency x Scaling Table 157: Parameter 519 FCD 300 series FCD 302 series Parameter 519 Frequency x Scaling Not converted 68 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 69 524 Motor Voltage 16-12 Motor Voltage 5.6.19 Conversion of Parameter 525 DC Link Voltage Table 163: Parameter 525 FCD 300 series FCD 302 series Parameter 525 DC Link Voltage 16-30 DC Link Voltage Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 69...
  • Page 70 16-62 Analog Input 53 5.6.24 Conversion of Parameter 531 Analog Input 60 Table 168: Parameter 531 FCD 300 series FCD 302 series Parameter 531 Analog Input 60 16-64 Analog Input 54 70 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 71 537 Heat Sink Temp 16-34 Heatsink Temp 5.6.30 Conversion of Parameter 538 Alarm Word Table 174: Parameter 538 FCD 300 series FCD 302 series Parameter 538 Alarm Word 14-72 Legacy Alarm Word Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 71...
  • Page 72 Pulse Input 29 14-67 Pulse Input #29 [Hz] 5.6.36 Conversion of Parameter 553 Display Text 1 Table 180: Parameter 553 FCD 300 series FCD 302 series Parameter 553 Display Text 1 Not converted 72 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...

  • Page 73: Fcd 300 Parameter Group

    604 Number of Over Temp. 15-04 Over Temp's 5.7.6 Conversion of Parameter 605 Numbers of Over Voltage Table 186: Parameter 605 FCD 300 series FCD 302 series Parameter 605 Numbers of Over Voltage 15-05 Over Volt's Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 73...
  • Page 74 610 Data Log: Feedback Not converted 5.7.12 Conversion of Parameter 611 Data Log: Motor Frequency Table 192: Parameter 611 FCD 300 series FCD 302 series Parameter 611 Data Log: Motor Frequency Not converted 74 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 75 616 Fault Log: Time 15-32 Fault Log: Time 5.7.18 Conversion of Parameter 617 Fault Log: Value Table 198: Parameter 617 FCD 300 series FCD 302 series Parameter 617 Fault Log: Value 15-31 Fault Log: Value Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 75...
  • Page 76 621 Name Plate: VLT® Type Not converted 5.7.23 Conversion of Parameter 622 Name Plate: Power Section Table 203: Parameter 622 FCD 300 series FCD 302 series Parameter 622 Name Plate: Power Section Not converted 76 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 77 627 Name Plate: Power ID No. Not converted 5.7.29 Conversion of Parameter 628 Name Plate: Application Type Table 209: Parameter 628 FCD 300 series FCD 302 series Parameter 628 Name Plate: Application Type Not converted Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 77...

  • Page 78: Fcd 300 Parameter Group

    Parameter 801 Baud Selection Not converted 5.8.3 Conversion of Parameter 802 Minimum Station Delay Table 215: Parameter 802 FCD 300 series FCD 302 series Parameter 802 Minimum Station Delay Not converted 78 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 79 [3] Bit 10 = 1 [1] CTW Valid, Active High 5.8.7 Conversion of Parameter 806 SAP Selection (FMS) Table 219: Parameter 806 FCD 300 series FCD 302 series Parameter 806 SAP Selection (FMS) Not converted Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 79...

  • Page 80: Fcd 300 Parameter Group

    904 PPO Type Select for DP Not converted 5.9.2 Conversion of Parameter 915 PCD Config Write Table 223: Parameter 915 FCD 300 series FCD 302 series Parameter 915 PCD Config Write 9-15 PCD Write Configuration 80 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 81 [417] Torque Limit Generator Mode 5.9.3 Conversion of Parameter 916 PCD Config Read Table 224: Parameter 916 FCD 300 series FCD 302 series Parameter 916 PCD Config Read 9-16 PCD Read Configuration Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 81...
  • Page 82 [1652] Feedback [Unit] [528] Digital Input [1660] Digital Input [529] Analog Input 53 [1662] Analog Input 53 [530] Analog Input 54 [1664] Analog Input 54 [531] Analog Input 60 [1664] Analog Input 54 82 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 83 [0] Disable [1] Enable [1] Enable Cyclic Master 5.9.8 Conversion of Parameter 953 Warning Parameter Table 229: Parameter 953 FCD 300 series FCD 302 series Parameter 953 Warning Parameter 9-53 PROFIBUS Warning Word Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 83...
  • Page 84 [1] Parameter Setup 1 [2] Parameter Setup 2 [2] Parameter Setup 2 [3] Parameter Setup 3 [3] Parameter Setup 3 [4] Parameter Setup 4 [4] Parameter Setup 4 [5] Active Setup [9] Active Setup 84 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 85 [1] Store All Setups 5.9.15 Conversion of Parameters 980–982 and 990–992 Modified Parameters Table 236: Parameters 980–982 and 990–992 FCD 300 series FCD 302 series Parameter 980–982, 990–992 Modified Parameters Not converted Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 85...
  • Page 86 Wrong ID sent by PLC. 1000 Internal fault occurred. 2000 Not configured. 4000 Timeout active. 8000 Warning 34 active. • Check 1.4.1 Intended Use 1.4.2 Hardware for more information on limitations. 86 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 87 • Bullet lists indicate other information and description of illustrations. • Italicized text indicates: Cross reference. Link. Footnote. Parameter name. Parameter group name. Parameter option. • All dimensions are in mm (inch). Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 87...
  • Page 88 PROFIBUS Cable Voltage Relay Cable Safety warning Drive firmware version Warning words Hardware switch settings Initial power-up Initialization Intended use Leakage current LED pattern PLC programming PROFIBUS firmware version PROFIBUS SSA command 88 | Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890...
  • Page 89 Operating Guide | VLT® FCD 300 PROFIBUS Converter MCA 117 Danfoss A/S © 2019.11 AQ289550754901en-000101 / 130R0890| 89...

  • Page 90: Aq289550754901En-000101

    Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specifications already agreed. All trademarks in this material are property of the respective companies.
