Parameter Mapping Lists
VLT 5000 series
Parameter 319 Terminal 42,
Output
Parameter 321 Terminal 45,
Output
Options [60] 0 – SyncRPM ⇒ 0
5 5
– 20 mA
[61] 0 – SyncRPM ⇒ 4
– 20 mA
[62] 0 – SyncRPM ⇒ 0
– 32000 p
[63] RPM at F max ⇒ 0
– 20 mA
[64] RPM at F max ⇒ 4
– 20 mA
[65] RPM at F max ⇒ 0
– 32000 p
Table 5.110 Conversion of Parameters 319 to 321
VLT 5000 series
Parameter 320 Terminal 42 Output,
pulse scaling
Range 1 – 32000 Hz
Table 5.111 Conversion of Parameter 320
VLT 5000 series
Parameter 322 Terminal 45 Output,
pulse scaling
Range 1 – 32000 Hz
Table 5.112 Conversion of Parameter 322
28
Operating Instructions
FC 302 series
Digital = Par. 5-32 DO X30/7
(MCB 101)
Analogue values= Par. 6-50
AO 42
Pulse = Par. 5-66 DO X30/6
Digital = Par. 5-33 DO X30/7
(MCB 101)
Analogue values= Par. 6-60
AO X30/8
Pulse = Par. 5-66 DO X30/6
Not supported
Not supported
Not supported
Par. 6-50 = [107] Speed
related to norm 0 - 20 mA
Par. 6-50 = [137] Speed
related to norm 4 - 20 mA
Par. 5-66 = [107] Speed
related to norm 0 – 32000p
Par. 5-68 = 32000
FC 302 series
5-68 Pulse Output Max
Freq #X30/6
0 – 32000 Hz
FC 302 series
5-68 Pulse Output Max
Freq #X30/6
0– 32000 Hz
Danfoss A/S © Rev. 2014-03-06 All rights reserved.
VLT 5000 series FC 302 series
Parameter 323, 326 5-40 Function Relay
Range 01 Relay Relay 1
04 Relay Relay 2
[0] No function Par. 5-40 = [0] No operation
[1] Control Ready Par. 5-40 = [1] Control Ready
[2] Ready signal Par. 5-40 = [2] Drive ready
[3] Ready - Remote Par. 5-40 = [3] Drive rdy/rem ctrl
Control
[4] Enabled, no Par. 5-40 = [4] Enable / no
warning warning
[5] Running Par. 5-40 = [5] VLT running
[6] Running, no Par. 5-40 = [6] Running / no
Warning warning
[7] Running within Par. 5-40 = [7] Run in range/no
range, no warning warn
[8] Run at Par. 5-40 = [8] Run on ref/no
reference, no warn
Warning
[9] Alarm Par. 5-40 = [9] Alarm
[10] Alarm or Par. 5-40 = [10] Alarm or
Warning Warning
[11] Torque limit Par. 5-40 = [11] At torque limit
[12] Out of current Par. 5-40 = [12] Out of current
range range
[13] Above I low Par. 5-40 = [13] Below current,
low
[14] Under I high Par. 5-40 = [14] Above current,
high
[15] Out of Par. 5-40 = [15] Out of speed
frequency range range
[16] Over f low Par. 5-40 = [16] Below speed
low
[17] Under f high Par.5-40 = [17] Above speed
high
[18] Out of Par. 5-40 = [18] Out of feedb.
feedback range Range
[19] Over feedback Par. 5-40 = [16] Below feedback
low
low
[20] Under Par. 5-40 = [17] Above feedback
feedback high
high
[21] Thermal Par. 5-40 = [21] Thermal
warning warning
Table 5.113 Conversion of Parameters 323 to 326
1)
1)
1)
1)
1)
1)
