Chapter 2
Print Settings
This is an executable menu item that reads and prints the settings used by the validator.
The response received from the validator after sending the ~DV (retrieves version), ~HT
(retrieves hardware settings), and ~PT8 (retrieves parameter settings) commands are
printed. Use the printout to view all the active settings the validator is using and to
determine if there is any invalid setting which may be causing problems.
The following is a sample printout:
F/W Version: X354
~HT Response:
[~HS###]SOS=
[~HP###]Beam
[c]HIGHcal=
[c]LOWcal=
[~Sh##]=
[~Sl##]=
[c]SCfact=
[c]min
[~HB#]baud=
[~LL]smt_decode=
[~LM##]chars=
[~LN##]num_bc=
[~LZ##]num_bc_exact=
[~LR#]No_Read_Enable=000
[~LF##]I25_Mod10_Chk=000
[~HQ#]output_mode=
[~HO#]oper_mode=
[~LA##]ansi=
[~LS##]min_scn=
[~LT#]sync_in=
[~LP#]sync_pol=
[~LX#]sync_typ=
[~LV##]sync_md=
[~PO#]port_sel=
[PC#]port_clear_md=
[Pt##]port_time=
[~LD##]
[~PR####]PRST=
[~HL#]ladder_code=
[~HJ####]ladd_start=
[~HK####]ladd_end=
[~HC####]ana_len=
[~HG####]ana_lenh=
[~HN####]pana_len=
[~HU####]freq=
[~HV###]GTLA_len=
[~HY###]snoise=
[~HX###]dist=
[~H=#]dyn_out=
[~H!###]zone_tol=
[~H@##]gt_%=
[~SN###]#scans=
[~Lp#]part=
[~Lt#]itfp=
[DACs]=
[~LQ#]p_out=
[~Lw,d]def=
[~L*]pnet=
[~LC##]I25min=
66
025
Shift= 000 024
088
004
088
004
044
cal= 031
003
343
003
001
000
001
001
005
003
001
000
001
000
005
000
099
%dec= 075
000200
000
0200
4000
1800
0950
0950
400
199
070
084
000
450
043
050
000
000
178 151 255 255
000
000 000
000
000
