Chapter 1

Power/Data

Cable

Wire Saddle

15. On the electronics side of the printer, position the ferrite on top of the upper DC

16. Route the power/data cable through the wire saddle as shown in Figure 9.

17. Plug the P10 connector end of the power/data cable into the J10 receptacle on the

NOTE:

J10

Ferrite

Figure 9. Position the Ferrite

motor. (Figure 9.)

controller board.

For SL5000r/T5000r Energy Star models see Figure 10 on page 25 .

Upper DC

Motor
