Chapter 1
If Label Length is less than 0.5 inches or Label Width is less than 2.0 inches, no demo
page will print.
To print and validate the bar code validation demo page:
1. Load the factory default configuration. (Refer to the Administrator's Manual.)
2. In the VALIDATOR menu, set Validator Funct. to Enable.
3. In the CALIBRATE CTRL menu, set Gap/Mark Sensing to Gap.
4. Load media.
5. In the CALIBRATE CTRL menu, run Auto Calibrate for proper gap sensing.
6. The printer must be offline. If the printer is in Menu mode, press the PAUSE key to
7. Press the TEST PRINT key to enter the Test Print menu. Continue to press TEST
8. Press the  key to print and validate the demo page. (If the  key is locked, unlock it
9. The printer will print one demo page.
10. To demonstrate a bad bar code reading, block the scanning beam with an opaque
11. Press PAUSE to take the printer offline.
12. Press  and  at the same time to lock the  key, then press PAUSE to place the
42
take the printer offline.
PRINT until Barcode Demo displays.
by pressing  and  at the same time.)
object while the bar code moves under the beam. When you block the beam, the
validator will generate a reading error and will perform a default error action. The
default setting for the Validator Action in the VALIDATOR menu is Retry Form.
Using the factory default settings, the printer will pull the label with the bad barcode
back, overstrike the entire label, reprint the barcodes on the next label and then
stop.
printer back online.
