Chapter 1

Installation and Removal

This section describes how to install the validator. To remove the validator, reverse the

steps of this procedure.

1. Set the printer power switch to O (Off).

WARNING

Always unplug the printer power cord from the printer or power outlet before

doing any installation procedure. Failure to remove power could result in injury

to you and damage the equipment. You will be instructed when to apply power.

2. Unplug the printer power cord from the printer or the AC power source.

Factory Installation

If your printer has a factory installed validator, the ferrite, cable, wire saddle, grommet,

and extended media width guide have already been installed. Go to "Install the

Validator" on page 27

If you are doing a field installation, you must install the ferrite, cable, wire saddle,

grommet, and extended media width guide. Go to "Install the Ferrite" on page 17.
