Install the Validator

Figure 12. Attaching the Validator to the Bracket
1. Using two 6-32 Phillips head screws, attach the validator to the bracket as shown in
Figure 12.
2. Use the appropriate holes on the bracket, depending on the media width.
Validator
Bracket
6-32 Phillips
Screw (2)
27
