Install the Ferrite

1. Loosen the two captive screws securing the top of the frame side cover. (Figure 2.)

2. Tilt the frame side cover back from the top and lift it until the tabs along the lower

edge disengage from the slots in the printer frame.

Captive Screw (2)

Frame Side Cover

Figure 2. Removing the Frame Side Cover
