Callout
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Related Information
"Back Panel Connector Locations" on page 42
■
"Back Panel Pinhole Switches" on page 45
■
"Troubleshooting Using the Server Front and Back Panel Status Indicators" on page 30
■
"Disconnect Cables From the Server" on page 59
■
"Reconnect Power and Data Cables" on page 192
■
"Identifying the Server Ports" on page 195
■
System Components
These sections describe the components of the server:
"Illustrated Parts Breakdown" on page 22
■
"Replaceable Units" on page 23
■
Description
PCIe slot 3
PCIe slot 4 (Oracle Flash Accelerator F640)
PCIe slot 5 (Oracle Flash Accelerator F640)
PCIe slot 6 (Oracle Flash Accelerator F640)
Serial management (SER MGT) RJ-45 serial port
Oracle Integrated Lights Out Manager (ILOM) service processor (SP) network management
(NET MGT) RJ-45 10/100/1000BASE-T port
Network (NET) 100/1000BASE-T RJ-45 Gigabit Ethernet (GbE) port: NET 0
USB 3.0 connector
System status LEDs: Locate Button/LED: white; Fault-Service Required: amber; System
OK: green
PCIe slot 7 (Oracle Dual Port QDR InfiniBand Adapter M4)
PCIe slot 8
PCIe slot 9
PCIe slot 10 (Oracle Flash Accelerator F640)
PCIe slot 11 (Oracle Storage 12 Gb SAS PCIe RAID HBA, Internal card)
About the Oracle Exadata Storage Server X7-2
System Components
21
