- Page 1 StorageTek LTO 1U Rackmount Media Tray Reference Guide Part Number: E38510-01 Release Date: February 2013 Submit comments about this document to STP_FEEDBACK_US@ORACLE.COM.
- Page 2 This software or hardware and documentation may provide access to or information on content, products, and services from third parties. Oracle Corporation and its affiliates are not responsible for and expressly disclaim all warranties of any kind with respect to third-party content, products, and services. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services.
-
Page 3: Table Of Contents
Contents About this guide....................5 Intended audience........................5 Document conventions and symbols. -
Page 5: About This Guide
Table 1 Document conventions Convention Element Blue text: (page 5) Cross-reference links and e-mail addresses Blue, underlined text: http://www.oracle.com website addresses Bold text Keys that are pressed Text typed into a GUI element, such as a box GUI elements that are clicked or selected, such as menu... -
Page 6: Rack Stability
Extend only one rack component at a time. Racks can become unstable if more than one component is extended. Technical support Telephone numbers for worldwide technical support are listed on the support website: http://www.oracle.com/us/support/ contact.html. Collect the following information before calling:... -
Page 7: Introduction
1 Introduction The 1U Rackmount Media Tray is a rack-mountable storage system capable of holding up to two half-height 5.25 inch devices. It is compatible with most standard 19-inch racks. There are two models of the 1U Rackmount Media Tray, one for SAS tape drives, the other for SCSI tape drives. -
Page 8: Media Tray Components
NOTE: The interface board has text, “Port 1–0” and “Port 2–0”, on the PCI board near the internal SAS connector, which also helps identify the routing to the external ports. NOTE: Power for all LTO–5 and later tape drives is supplied through the SAS cable. For all earlier models of LTO tape drive, a separate power cable is required. -
Page 9: Media Tray Internal Components (Sas Version Shown)
Media tray internal components (SAS version shown) 1. Device 2. Device blank 3. Power supply 4. Fan assemblies (2) 5. SAS Repeater Board (SAS Models only) Figure 5 Internal components StorageTek1U Rackmount Media Tray... -
Page 11: Device Installation
2 Device installation A 3/16” (5mm) flat-blade screwdriver or T-15 Torx driver may be required to install a device in the 1U media tray. CAUTION: To avoid damaging the equipment due to electrostatic discharge, be sure to review and practice the procedures in Electrostatic discharge (page 23) before handling the devices. - Page 12 Figure 8 Removing the mounting brackets Install the mounting brackets to the sides of the device. Figure 9 Installing the mounting brackets CAUTION: When installing an LTO half-height tape drive, it is particularly important that you use the 6 mm M3 screws provided with the drive.
-
Page 13: Cabling With Two Devices
Figure 11 Attaching the cables 1. Power 2. Signal 3. SCSI ID selector (SCSI drives only) NOTE: Fold excess cable length and secure with the clips provided in the media tray. Replace the top access panel as shown. Figure 12 Replacing the access panel Cabling with two devices The 1U Media Tray supports operation of two devices. -
Page 14: One Device Per Scsi Bus
1. Device 1 2. Device 2 3. SCSI bus 1 cable; SCSI connector nearest terminator 4. SCSI bus 2 cable (not used) is used for device 2, center connector is used for device 5. SCSI ID cables, one for each device Figure 13 Two-device SCSI configuration NOTE: When adding a second device for configurations using a single SCSI bus. - Page 15 1. Device 1 2. Device 2 3. SCSI bus 1 cable, SCSI connector nearest terminator 4. SCSI bus 2 cable, SCSI connector nearest terminator is used for device 1 is used for device 2 5. SCSI ID cables, one for each device Figure 14 Single-device SCSI configuration CAUTION: To prevent possible data errors, when there is only one device on a SCSI bus that device must be connected to...
-
Page 17: Rack Installation
3 Rack installation Rail mounting kit The rack rails supplied with the 1U rackmount media tray can be used to install the unit in racks that have round, square, or threaded holes in the vertical mounting bars. The rails will fit racks with 23 - 34 inches (58 - 86 cm) separation between the front and rear vertical mounting bars. -
Page 18: Before You Begin
Before you begin If you are installing the media tray in a rack with unmarked holes in the vertical mounting bars, identify and mark the correct mounting holes in the rack before you begin rail installation. CAUTION: It is important to make sure that the rack components are level. To ensure that the 1U media tray is installed correctly it may be necessary to measure the height of the correct mounting holes in the front and rear vertical mounting bars. -
Page 19: Installation In Racks With 10-32 Threaded Holes
Insert the pins in the front mounting plate of the outer rack rails into the previously marked holes in the front vertical mounting bars of the rack. The rack rails will lock securely into place. Figure 17 Inserting the pins in racks with round or square holes NOTE: To remove the rail for repositioning, push the spring-loaded tab (3) on the outside of the rack rail and slide it forward (4). - Page 20 Remove the pins and threaded plates from both ends of each outer rack rail. These pieces will not be used. Figure 19 Removing the pins in racks with 10–32 threaded holes NOTE: The ends of the rack rails are marked FRONT and REAR for proper orientation. Attach the front mounting plate of each outer rail to the rack using four 10-32 screws in the previously marked holes in the front vertical mounting bars of the rack.
-
Page 21: Completing The Installation
Completing the installation Extend the stabilizing feet, if provided, on your rack. Extend the left and right rack rails from the front of the rack. Align the rear of the component rails on the media tray with the front ends of the rack rails, then slide the unit fully into the rack. - Page 22 Figure 24 Installing the cable support clips Turn on the power to the media tray with the front panel power button. Rack installation...
-
Page 23: A Electrostatic Discharge
A Electrostatic discharge Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the device. -
Page 25: B Specifications
B Specifications Specification S.A.E. Metric Dimensions: Height 1.75 in 4.44 cm Depth 25.25 in 64.1 cm Width 19.0 in 48.3 cm Weight (1 device installed) 20 lb 9.07 kg Input power requirements 90 to 264 VAC 90 to 264 VAC 2.4 A 47 - 63 Hz 2.4 A 47 - 63 Hz 140 W *... -
Page 27: Index
Index audience, 5 rack stability warning, 6 rack systems cable configurations supported, 7 one device per SCSI bus, 14 racking SAS, 13 the media tray, 17 SCSI, 13 warnings, 17 two drives on one SCSI bus, 13 rails components installation, 17 fear panel , 8 front panel, 8 internal , 9...
