1010/2020 I A
NSTALLATION ND
A Z
NNUNCIATOR ONE
Type I.D.
AZON
AACT
AGZN ANN GLOBAL ZON
A I
NNUNCIATOR NPUT
Type I.D.
AINP
A O
NNUNCIATOR UTPUT
Type I.D.
ACON
AFCM ANN FORC MAN
P M
ROGRAMMING ANUAL
Display Label
ANN ZONE
ALM ACTIVATE
Display Label
ANN INPUT
Display Label
ANN CONTROL
C
OPYRIGHT
Type of Device
Annunciator Point, In the case of an ACM-
16at, AZON acts as a Zone Isolate Facility, or
can be used to isolate a module, and will
display an alarm state if the point isolated is in
alarm.
Annunciator Point, when using an ACM 16AT,
AACT is used to activate a zone.
Annunciator Point, when using an ACM16AT,
AGZN is used to isolate all inputs to any
Forward Zone associated with this Type ID. The
zone needs to be the First zone in the CBE for
an input device.
Type of Device
Annunciator Point that indicates the state of
any input mapped to it. (Zone Module or
Detector)
It does not display an alarm, if the device is
isolated.
Type of Device
Annunciator Point that can be used for
manual control of relays to activate solenoids
on sprinkler installations, it also indicates the
state of any CMX Control Module, or XP5-C
relay mapped to it.
Annunciator Point Used for fan controls
Start/Stop, that is not deactivated upon system
reset, and similar applications only with an
FRCM control device.
© 2000, N I P
OTIFIER NERTIA
L
TY TD
P 67
AGE
