Specifications

9 Specifications

9.1 Electrical Data

9.1.1 Mains Supply 3x380–480 V AC
FC 202
High/normal load
(High overload=150% current during 60 s,
normal overload=110% current during 60 s)
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Enclosure size
Output current (3-phase)
Continuous (at 400 V) [A]
Intermittent (60 s overload)
(at 400 V) [A]
Continuous (at 460/500 V) [A]
Intermittent (60 s overload)
(at 460/500 V) [A]
Continuous kVA (at 400 V) [kVA]
Continuous kVA (at 460 V) [kVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/500 V) [A]
Maximum number and size of cables
per phase (E1h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Brake or regeneration [mm 2 (AWG)
Maximum number and size of cables
per phase (E3h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Load share or regeneration [mm
Maximum external mains fuses [A]
Estimated power loss at 400 V [W]
Estimated power loss at 460 V [W]
Efficiency 4)
Output frequency
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Fan power card overtemperature trip [°C (°F)]
Active in-rush card overtemperature trip
[°C (°F)]
Table 9.1 Technical Specifications, Mains Supply 3x380–480 V AC
MG22A102
Operating Guide
N355
HO
315
450
E1h/E3h
600
900
540
810
416
430
590
531
2 1) 5x240 (5x500 mcm)
(AWG)]
2 1) 4x240 (4x500 mcm)
(AWG)
1) 2x185 (2x350 mcm)
2 (AWG)] 1) 6x240 (6x500 mcm)
2 1) 2x185 (2x350 mcm)
(AWG)
2 1) 4x185 (4x350 mcm)
(AWG)
800
2)
3) 4) 6794
3)4) 6118
0.98
0–590 Hz
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
