Electrical Installation
5.7 Terminal Dimensions
5.7.1 E1h Terminal Dimensions
5
5
6X
613 (24.1)
1
515 (20.3)
485 (19.1)
200 (7.9)
1
Mains terminals
2
Brake or regeneration terminals
Illustration 5.6 E1h Terminal Dimensions (Front View)
30
0 (0.0)
Danfoss A/S © 01/2017 All rights reserved.
VLT® AQUA Drive FC 202
3
Motor terminals
4
Ground terminals, M10 nut
2
721 (28.4)
3
4
5
MG22A102
