Danfoss VLT AQUA Drive FC 202 Operating Manual page 18

Mechanical Installation
1
4 4
2
3
4
1 Enclosure
2 Pedestal
3 M10 nut
Illustration 4.4 Pedestal to Enclosure Back Mounting Points
1
2
1 Enclosure
2 Pedestal
Illustration 4.5 Pedestal to Enclosure Mounting Points
16
VLT® AQUA Drive FC 202
5
6
4 Slotted hole in enclosure
5 Bolt at rear of pedestal
6 Locking bracket
3
3 M10x30 fasteners
(rear corner bolts not
shown)
– –
Danfoss A/S © 01/2017 All rights reserved.
4.7.3 Creating Cable Openings
The gland plate is a sheet of metal with studs along the
outer edge. The gland plate provides cable entry and cable
termination points, and must be installed to maintain the
IP21/IP54 (Type 1/Type 12) protection rating. The plate is
placed between the drive enclosure and the pedestal.
Depending on stud orientation, the plate can be installed
from inside the enclosure or the pedestal. For gland plate
dimensions, see chapter 9.8.1 E1h Exterior Dimensions.
Refer to Illustration 4.6 for the following steps.
1. Create cable entry holes in the gland plate using
a sheet metal punch.
2. Insert the gland plate using 1 of the following
methods:
2a To insert the gland plate through the
pedestal, slide the gland plate through
the slot (4) in the front of the pedestal.
2b To insert the gland plate through the
enclosure, angle the gland plate until it
can be slid under the slotted brackets.
3. Align the studs on the gland plate to the holes in
the pedestal and secure with 10 M5 nuts (2).
4. Torque each nut to 2.3 Nm (20 in-lb).
1
2
1 Cable entry hole
2 M5 nut
3 Gland plate
Illustration 4.6 Installing the Gland Plate
3
4
4 Slot in pedestal base
5 Front cover/grill
– –
MG22A102
