9.8 Enclosure Dimensions

9.8.1 E1h Exterior Dimensions
2043
(80.4)
2002
(78.8)
Illustration 9.2 Front View of E1h
MG22A102
Operating Guide
1553
(61.1)
1393
(54.9)
912
(35.9)
Danfoss A/S © 01/2017 All rights reserved.
22 (0.8)
3X
393 (15.5)
602 (23.7)
13 (0.5)
9 9
83
