Introduction

1 Introduction

1.1 Purpose of the Manual

This operating guide provides information for safe instal-
lation and commissioning of the VLT
enclosure size E (E1h, E2h, E3h, and E4h).
The operating guide is intended for use by qualified
personnel. To use the unit safely and professionally, read
and follow this operating guide. Pay particular attention to
the safety instructions and general warnings. Always keep
the operating guide with the drive.
®
VLT is a registered trademark.

1.2 Additional Resources

Other resources are available to understand advanced E1h–
E4h drive functions and programming.
•
®
The VLT AQUA Drive FC 202 Programming Guide
provides greater detail on working with
parameters and aqua application examples.
•
®
The VLT AQUA Drive FC 202, 110–1400 kW Design
Guide provides detailed capabilities and
functionality to design motor control systems for
aqua applications.
•
The Safe Torque Off Operating Guide.
Supplementary publications and manuals are available
from Danfoss. See drives.danfoss.com/knowledge-center/
technical-documentation/ for listings.

1.3 Manual and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the version of the manual and the corresponding software
version.
Manual version Remarks
MG22A1xx Initial release
Table 1.1 Manual and Software Version
MG22A102
Operating Guide

1.4 Approvals and Certifications

®
drives in an
More approvals and certifications are available. Contact the
local Danfoss office or partner. Drives of voltage T7 (525–
690 V) are UL certified for only 525–600 V.
The drive complies with UL 61800-5-1 thermal memory
retention requirements. For more information, refer to the
section Motor Thermal Protection in the product-specific
design guide.
NOTICE
IMPOSED LIMITATIONS ON THE OUTPUT
FREQUENCY
From software version 1.99, the output frequency of the
drive is limited to 590 Hz due to export control
regulations.
1.4.1 Compliance with ADN
For compliance with the European Agreement concerning
International Carriage of Dangerous Goods by Inland
Waterways (ADN), refer to ADN-compliant Installation in the
design guide.

1.5 Disposal

Software version
2.70
Danfoss A/S © 01/2017 All rights reserved.
Table 1.2 Approvals and Certifications
Do not dispose of equipment containing
electrical components together with
domestic waste.
Collect it separately in accordance with
local and currently valid legislation.
1 1
