1.7. Power ON/OFF Switch

The power ON/OFF switch (1) turns the printer's power supply ON or OFF.
1
After switched ON the printer an internal self-test which checks the electronics, the print head
carriage movement and the interface will be performed.
At first the yellow LED on the Operator Panel is lighting up and the display shows TEST.....0.1
(bootstrap). In the next step the yellow LED will be dark, the green LED lights up and the display
shows TEST....FW..0101234 (version of the firmware).
If the message INSTALL RIBBON is shown, follow the steps in paragraph 1.8 installing the
Ribbon Cassette.
If the message INSTALL RIBBON is shown, follow the steps in paragraph 1.8 installing the
Ribbon Cassette.
After inserting the ribbon press to continue. When the internal test has been completed
successfully the display shows READY 1 ELQ or BUSY 1 ELQ in case data has already been
transmitted.
If the display shows anything different, please refer to chapter 4 Troubleshooting and
Note:
Diagnostics.
1-9
